Beams

Demo

Quick Start

beams.py
from terminaltexteffects.effects.effect_beams import Beams

effect = Beams("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Creates beams which travel over the canvas illuminating the characters.

Classes:

Name Description
Beams

Creates beams which travel over the canvas illuminating the characters.
BeamsConfig

Configuration for the Beams effect.
BeamsIterator

Iterates over the Beams effect. Does not normally need to be called directly.

Beams

Bases: BaseEffect[BeamsConfig]

Creates beams which travel over the canvas illuminating the characters.

Attributes:

Name Type Description
effect_config BeamsConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_beams.py
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
class Beams(BaseEffect[BeamsConfig]):
    """Creates beams which travel over the canvas illuminating the characters.

    Attributes:
        effect_config (BeamsConfig): Configuration for the effect.
        terminal_config (tte.TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[BeamsConfig]:
        return BeamsConfig

    @property
    def _iterator_cls(self) -> type[BeamsIterator]:
        return BeamsIterator

BeamsConfig dataclass

Bases: ArgsDataClass

Configuration for the Beams effect.

Attributes:

Name Type Description
beam_row_symbols tuple[str, ...] | str

Symbols to use for the beam effect when moving along a row. Strings will be used in sequence to create an animation.
beam_column_symbols tuple[str, ...] | str

Symbols to use for the beam effect when moving along a column. Strings will be used in sequence to create an animation.
beam_delay int

Number of frames to wait before adding the next group of beams. Beams are added in groups of size random(1, 5). Valid values are n > 0.
beam_row_speed_range tuple[int, int]

Speed range of the beam when moving along a row. Valid values are n > 0.
beam_column_speed_range tuple[int, int]

Speed range of the beam when moving along a column. Valid values are n > 0.
beam_gradient_stops tuple[Color, ...]

Tuple of colors for the beam, a gradient will be created between the colors.
beam_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops. Valid values are n > 0.
beam_gradient_frames int

Number of frames to display each gradient step. Increase to slow down the gradient animation. Valid values are n > 0.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the wipe gradient.
final_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops. Valid values are n > 0.
final_gradient_frames int

Number of frames to display each gradient step. Increase to slow down the gradient animation.
final_gradient_direction Direction

Direction of the final gradient.
final_wipe_speed int

Speed of the final wipe as measured in diagonal groups activated per frame. Valid values are n > 0.
Source code in terminaltexteffects/effects/effect_beams.py
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
@argclass(
    name="beams",
    help="Create beams which travel over the canvas illuminating the characters behind them.",
    description="beams | Create beams which travel over the canvas illuminating the characters behind them.",
    epilog=(
        "Example: terminaltexteffects beams --beam-row-symbols ▂ ▁ _ --beam-column-symbols ▌ ▍ ▎ ▏ --beam-delay "
        "10 --beam-row-speed-range 10-40 --beam-column-speed-range 6-10 --beam-gradient-stops ffffff 00D1FF "
        "8A008A --beam-gradient-steps 2 8 --beam-gradient-frames 2 --final-gradient-stops 8A008A 00D1FF "
        "ffffff --final-gradient-steps 12 --final-gradient-frames 5 --final-gradient-direction vertical "
        "--final-wipe-speed 1"
    ),
)
@dataclass
class BeamsConfig(ArgsDataClass):
    """Configuration for the Beams effect.

    Attributes:
        beam_row_symbols (tuple[str, ...] | str): Symbols to use for the beam effect when moving along a row. Strings
            will be used in sequence to create an animation.
        beam_column_symbols (tuple[str, ...] | str): Symbols to use for the beam effect when moving along a column.
            Strings will be used in sequence to create an animation.
        beam_delay (int): Number of frames to wait before adding the next group of beams. Beams are added in groups
            of size random(1, 5). Valid values are n > 0.
        beam_row_speed_range (tuple[int, int]): Speed range of the beam when moving along a row. Valid values are n > 0.
        beam_column_speed_range (tuple[int, int]): Speed range of the beam when moving along a column.
            Valid values are n > 0.
        beam_gradient_stops (tuple[tte.Color, ...]): Tuple of colors for the beam, a gradient will be created between
            the colors.
        beam_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps will
            create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.
            Valid values are n > 0.
        beam_gradient_frames (int): Number of frames to display each gradient step. Increase to slow down the gradient
            animation. Valid values are n > 0.
        final_gradient_stops (tuple[tte.Color, ...]): Tuple of colors for the wipe gradient.
        final_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps will
            create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.
            Valid values are n > 0.
        final_gradient_frames (int): Number of frames to display each gradient step. Increase to slow down the
            gradient animation.
        final_gradient_direction (tte.Gradient.Direction): Direction of the final gradient.
        final_wipe_speed (int): Speed of the final wipe as measured in diagonal groups activated per frame.
            Valid values are n > 0.

    """

    beam_row_symbols: tuple[str, ...] | str = ArgField(
        cmd_name="--beam-row-symbols",
        type_parser=argvalidators.Symbol.type_parser,
        nargs="+",
        default=("▂", "▁", "_"),
        metavar=argvalidators.Symbol.METAVAR,
        help=(
            "Symbols to use for the beam effect when moving along a row. "
            "Strings will be used in sequence to create an animation."
        ),
    )  # type: ignore[assignment]

    (
        "tuple[str, ...] | str : Symbols to use for the beam effect when moving along a row. "
        "Strings will be used in sequence to create an animation."
    )

    beam_column_symbols: tuple[str, ...] | str = ArgField(
        cmd_name="--beam-column-symbols",
        type_parser=argvalidators.Symbol.type_parser,
        nargs="+",
        default=("▌", "▍", "▎", "▏"),
        metavar=argvalidators.Symbol.METAVAR,
        help=(
            "Symbols to use for the beam effect when moving along a column. "
            "Strings will be used in sequence to create an animation."
        ),
    )  # type: ignore[assignment]

    (
        "tuple[str, ...] | str : Symbols to use for the beam effect when moving along a column. "
        "Strings will be used in sequence to create an animation."
    )

    beam_delay: int = ArgField(
        cmd_name="--beam-delay",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=10,
        metavar=argvalidators.PositiveInt.METAVAR,
        help=(
            "Number of frames to wait before adding the next group of beams. "
            "Beams are added in groups of size random(1, 5)."
        ),
    )  # type: ignore[assignment]

    (
        "int : Number of frames to wait before adding the next group of beams. "
        "Beams are added in groups of size random(1, 5)."
    )

    beam_row_speed_range: tuple[int, int] = ArgField(
        cmd_name="--beam-row-speed-range",
        type_parser=argvalidators.PositiveIntRange.type_parser,
        default=(10, 40),
        metavar=argvalidators.PositiveIntRange.METAVAR,
        help="Speed range of the beam when moving along a row.",
    )  # type: ignore[assignment]

    "tuple[int, int] : Speed range of the beam when moving along a row."

    beam_column_speed_range: tuple[int, int] = ArgField(
        cmd_name="--beam-column-speed-range",
        type_parser=argvalidators.PositiveIntRange.type_parser,
        default=(6, 10),
        metavar=argvalidators.PositiveIntRange.METAVAR,
        help="Speed range of the beam when moving along a column.",
    )  # type: ignore[assignment]

    "tuple[int, int] : Speed range of the beam when moving along a column."

    beam_gradient_stops: tuple[tte.Color, ...] = ArgField(
        cmd_name="--beam-gradient-stops",
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(tte.Color("ffffff"), tte.Color("00D1FF"), tte.Color("8A008A")),
        metavar="(XTerm [0-255] OR RGB Hex [000000-ffffff])",
        help="Space separated, unquoted, list of colors for the beam, a gradient will be created between the colors.",
    )  # type: ignore[assignment]

    "tuple[tte.Color, ...] : Tuple of colors for the beam, a gradient will be created between the colors."

    beam_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--beam-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=(2, 8),
        metavar=argvalidators.PositiveInt.METAVAR,
        help=(
            "Space separated, unquoted, numbers for the of gradient steps to use. "
            "More steps will create a smoother and longer gradient animation. "
            "Steps are paired with the colors in final-gradient-stops."
        ),
    )  # type: ignore[assignment]

    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. "
        "More steps will create a smoother and longer gradient animation. "
        "Steps are paired with the colors in final-gradient-stops."
    )

    beam_gradient_frames: int = ArgField(
        cmd_name="--beam-gradient-frames",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=2,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of frames to display each gradient step. Increase to slow down the gradient animation.",
    )  # type: ignore[assignment]

    "int : Number of frames to display each gradient step. Increase to slow down the gradient animation."

    final_gradient_stops: tuple[tte.Color, ...] = ArgField(
        cmd_name="--final-gradient-stops",
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(tte.Color("8A008A"), tte.Color("00D1FF"), tte.Color("ffffff")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the wipe gradient.",
    )  # type: ignore[assignment]

    "tuple[tte.Color, ...] : Tuple of colors for the wipe gradient."

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--final-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help=(
            "Space separated, unquoted, numbers for the of gradient steps to use. "
            "More steps will create a smoother and longer gradient animation. "
            "Steps are paired with the colors in final-gradient-stops."
        ),
    )  # type: ignore[assignment]

    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. "
        "More steps will create a smoother and longer gradient animation. "
        "Steps are paired with the colors in final-gradient-stops."
    )

    final_gradient_frames: int = ArgField(
        cmd_name="--final-gradient-frames",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=5,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of frames to display each gradient step. Increase to slow down the gradient animation.",
    )  # type: ignore[assignment]

    "int : Number of frames to display each gradient step. Increase to slow down the gradient animation."

    final_gradient_direction: tte.Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=tte.Gradient.Direction.VERTICAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]

    "tte.Gradient.Direction : Direction of the final gradient."

    final_wipe_speed: int = ArgField(
        cmd_name="--final-wipe-speed",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=1,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Speed of the final wipe as measured in diagonal groups activated per frame.",
    )  # type: ignore[assignment]

    "int : Speed of the final wipe as measured in diagonal groups activated per frame."

    @classmethod
    def get_effect_class(cls) -> type[Beams]:
        """Return the effect class associated with this configuration."""
        return Beams

beam_column_speed_range = ArgField(cmd_name='--beam-column-speed-range', type_parser=argvalidators.PositiveIntRange.type_parser, default=(6, 10), metavar=argvalidators.PositiveIntRange.METAVAR, help='Speed range of the beam when moving along a column.') class-attribute instance-attribute

tuple[int, int] : Speed range of the beam when moving along a column.

beam_column_symbols = ArgField(cmd_name='--beam-column-symbols', type_parser=argvalidators.Symbol.type_parser, nargs='+', default=('▌', '▍', '▎', '▏'), metavar=argvalidators.Symbol.METAVAR, help='Symbols to use for the beam effect when moving along a column. Strings will be used in sequence to create an animation.') class-attribute instance-attribute

tuple[str, ...] | str : Symbols to use for the beam effect when moving along a column. Strings will be used in sequence to create an animation.

beam_delay = ArgField(cmd_name='--beam-delay', type_parser=argvalidators.PositiveInt.type_parser, default=10, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to wait before adding the next group of beams. Beams are added in groups of size random(1, 5).') class-attribute instance-attribute

int : Number of frames to wait before adding the next group of beams. Beams are added in groups of size random(1, 5).

beam_gradient_frames = ArgField(cmd_name='--beam-gradient-frames', type_parser=argvalidators.PositiveInt.type_parser, default=2, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to display each gradient step. Increase to slow down the gradient animation.') class-attribute instance-attribute

int : Number of frames to display each gradient step. Increase to slow down the gradient animation.

beam_gradient_steps = ArgField(cmd_name='--beam-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=(2, 8), metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, numbers for the of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.

beam_gradient_stops = ArgField(cmd_name='--beam-gradient-stops', type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(tte.Color('ffffff'), tte.Color('00D1FF'), tte.Color('8A008A')), metavar='(XTerm [0-255] OR RGB Hex [000000-ffffff])', help='Space separated, unquoted, list of colors for the beam, a gradient will be created between the colors.') class-attribute instance-attribute

tuple[tte.Color, ...] : Tuple of colors for the beam, a gradient will be created between the colors.

beam_row_speed_range = ArgField(cmd_name='--beam-row-speed-range', type_parser=argvalidators.PositiveIntRange.type_parser, default=(10, 40), metavar=argvalidators.PositiveIntRange.METAVAR, help='Speed range of the beam when moving along a row.') class-attribute instance-attribute

tuple[int, int] : Speed range of the beam when moving along a row.

beam_row_symbols = ArgField(cmd_name='--beam-row-symbols', type_parser=argvalidators.Symbol.type_parser, nargs='+', default=('▂', '▁', '_'), metavar=argvalidators.Symbol.METAVAR, help='Symbols to use for the beam effect when moving along a row. Strings will be used in sequence to create an animation.') class-attribute instance-attribute

tuple[str, ...] | str : Symbols to use for the beam effect when moving along a row. Strings will be used in sequence to create an animation.

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=tte.Gradient.Direction.VERTICAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

tte.Gradient.Direction : Direction of the final gradient.

final_gradient_frames = ArgField(cmd_name='--final-gradient-frames', type_parser=argvalidators.PositiveInt.type_parser, default=5, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to display each gradient step. Increase to slow down the gradient animation.') class-attribute instance-attribute

int : Number of frames to display each gradient step. Increase to slow down the gradient animation.

final_gradient_steps = ArgField(cmd_name='--final-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, numbers for the of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Steps are paired with the colors in final-gradient-stops.

final_gradient_stops = ArgField(cmd_name='--final-gradient-stops', type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(tte.Color('8A008A'), tte.Color('00D1FF'), tte.Color('ffffff')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the wipe gradient.') class-attribute instance-attribute

tuple[tte.Color, ...] : Tuple of colors for the wipe gradient.

final_wipe_speed = ArgField(cmd_name='--final-wipe-speed', type_parser=argvalidators.PositiveInt.type_parser, default=1, metavar=argvalidators.PositiveInt.METAVAR, help='Speed of the final wipe as measured in diagonal groups activated per frame.') class-attribute instance-attribute

int : Speed of the final wipe as measured in diagonal groups activated per frame.

get_effect_class() classmethod

Return the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_beams.py
241
242
243
244
@classmethod
def get_effect_class(cls) -> type[Beams]:
    """Return the effect class associated with this configuration."""
    return Beams

BeamsIterator

Bases: BaseEffectIterator[BeamsConfig]

Iterator for the Beams effect.

Source code in terminaltexteffects/effects/effect_beams.py
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
class BeamsIterator(BaseEffectIterator[BeamsConfig]):
    """Iterator for the Beams effect."""

    class Group:
        """Represents a group of characters."""

        def __init__(
            self,
            characters: list[tte.EffectCharacter],
            direction: str,
            terminal: tte.Terminal,
            args: BeamsConfig,
        ) -> None:
            """Initialize the Group."""
            self.characters = characters
            self.direction: str = direction
            self.terminal = terminal
            direction_speed_range = {
                "row": (args.beam_row_speed_range[0], args.beam_row_speed_range[1]),
                "column": (args.beam_column_speed_range[0], args.beam_column_speed_range[1]),
            }
            self.speed = random.randint(direction_speed_range[direction][0], direction_speed_range[direction][1]) * 0.1
            self.next_character_counter: float = 0
            if self.direction == "row":
                self.characters.sort(key=lambda character: character.input_coord.column)
            elif self.direction == "column":
                self.characters.sort(key=lambda character: character.input_coord.row)
            if random.choice([True, False]):
                self.characters.reverse()

        def increment_next_character_counter(self) -> None:
            """Increment the counter for the next character."""
            self.next_character_counter += self.speed

        def get_next_character(self) -> tte.EffectCharacter | None:
            """Get the next character in the group.

            If the next character is already active, determined by having an active scene, the active
            scene is reset and None is returned. Otherwise, the next character is returned and the character
            is made visible.

            Returns:
                tte.EffectCharacter | None: The next character if the character or None if the character is
                    already active.

            """
            self.next_character_counter -= 1
            next_character = self.characters.pop(0)
            if next_character.animation.active_scene:
                next_character.animation.active_scene.reset_scene()
                return_value = None
            else:
                self.terminal.set_character_visibility(next_character, is_visible=True)
                return_value = next_character
            next_character.animation.activate_scene(next_character.animation.query_scene("beam_" + self.direction))
            return return_value

        def complete(self) -> bool:
            """Check if the group is complete.

            Returns:
                bool: True if the group is complete, False otherwise.

            """
            return not self.characters

    def __init__(self, effect: Beams) -> None:
        """Initialize the BeamsIterator.

        Args:
            effect (Beams): The Beams effect instance.

        """
        super().__init__(effect)
        self.pending_groups: list[BeamsIterator.Group] = []
        self.character_final_color_map: dict[tte.EffectCharacter, tte.ColorPair] = {}
        self.active_groups: list[BeamsIterator.Group] = []
        self.delay = 0
        self.phase = "beams"
        self.final_wipe_groups = self.terminal.get_characters_grouped(
            tte.Terminal.CharacterGroup.DIAGONAL_TOP_LEFT_TO_BOTTOM_RIGHT,
        )
        self.build()

    def build(self) -> None:
        """Build the initial state for the Beams effect."""
        final_gradient = tte.Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters(outer_fill_chars=True, inner_fill_chars=True):
            if character.is_fill_character:
                self.character_final_color_map[character] = tte.ColorPair(fg="000000")
                continue
            if self.terminal.config.existing_color_handling == "dynamic" and self.preexisting_colors_present:
                fg_color = tte.Color("ffffff")
                bg_color = None
                if character.animation.input_fg_color:
                    fg_color = character.animation.input_fg_color
                if character.animation.input_bg_color:
                    bg_color = character.animation.input_bg_color
                self.character_final_color_map[character] = tte.ColorPair(fg=fg_color, bg=bg_color)
            else:
                self.character_final_color_map[character] = tte.ColorPair(
                    fg=final_gradient_mapping[character.input_coord],
                )

        beam_gradient = tte.Gradient(*self.config.beam_gradient_stops, steps=self.config.beam_gradient_steps)
        groups: list[BeamsIterator.Group] = []
        for row in self.terminal.get_characters_grouped(
            tte.Terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
            outer_fill_chars=True,
            inner_fill_chars=True,
        ):
            groups.append(BeamsIterator.Group(row, "row", self.terminal, self.config))  # noqa: PERF401
        for column in self.terminal.get_characters_grouped(
            tte.Terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
            outer_fill_chars=True,
            inner_fill_chars=True,
        ):
            groups.append(BeamsIterator.Group(column, "column", self.terminal, self.config))  # noqa: PERF401
        for group in groups:
            for character in group.characters:
                beam_row_scn = character.animation.new_scene(scene_id="beam_row")
                beam_column_scn = character.animation.new_scene(scene_id="beam_column")
                brigthen_scn = character.animation.new_scene(scene_id="brighten")
                beam_row_scn.apply_gradient_to_symbols(
                    self.config.beam_row_symbols,
                    self.config.beam_gradient_frames,
                    fg_gradient=beam_gradient,
                )
                beam_column_scn.apply_gradient_to_symbols(
                    self.config.beam_column_symbols,
                    self.config.beam_gradient_frames,
                    fg_gradient=beam_gradient,
                )
                fg_fade_gradient = bg_fade_gradient = fg_brighten_gradient = bg_brighten_gradient = None
                char_fg_color = self.character_final_color_map[character].fg_color
                char_bg_color = self.character_final_color_map[character].bg_color
                if char_fg_color:
                    faded_fg_color = character.animation.adjust_color_brightness(char_fg_color, 0.3)
                    fg_fade_gradient = tte.Gradient(char_fg_color, faded_fg_color, steps=10)
                    fg_brighten_gradient = tte.Gradient(faded_fg_color, char_fg_color, steps=10)
                if char_bg_color:
                    faded_bg_color = character.animation.adjust_color_brightness(char_bg_color, 0.3)
                    bg_fade_gradient = tte.Gradient(char_bg_color, faded_bg_color, steps=10)
                    bg_brighten_gradient = tte.Gradient(faded_bg_color, char_bg_color, steps=10)

                beam_row_scn.apply_gradient_to_symbols(
                    character.input_symbol,
                    5,
                    fg_gradient=fg_fade_gradient,
                    bg_gradient=bg_fade_gradient,
                )
                beam_column_scn.apply_gradient_to_symbols(
                    character.input_symbol,
                    5,
                    fg_gradient=fg_fade_gradient,
                    bg_gradient=bg_fade_gradient,
                )
                brigthen_scn.apply_gradient_to_symbols(
                    character.input_symbol,
                    self.config.final_gradient_frames,
                    fg_gradient=fg_brighten_gradient,
                    bg_gradient=bg_brighten_gradient,
                )

        self.pending_groups = groups
        random.shuffle(self.pending_groups)

    def __next__(self) -> str:
        """Return the next frame in the effect."""
        if self.phase != "complete" or self.active_characters:
            if self.phase == "beams":
                if not self.delay:
                    if self.pending_groups:
                        for _ in range(random.randint(1, 5)):
                            if self.pending_groups:
                                self.active_groups.append(self.pending_groups.pop(0))
                    self.delay = self.config.beam_delay
                else:
                    self.delay -= 1
                for group in self.active_groups:
                    group.increment_next_character_counter()
                    if int(group.next_character_counter) > 1:
                        for _ in range(int(group.next_character_counter)):
                            if not group.complete():
                                next_char = group.get_next_character()
                                if next_char:
                                    self.active_characters.add(next_char)
                self.active_groups = [group for group in self.active_groups if not group.complete()]
                if not self.pending_groups and not self.active_groups and not self.active_characters:
                    self.phase = "final_wipe"
            elif self.phase == "final_wipe":
                if self.final_wipe_groups:
                    for _ in range(self.config.final_wipe_speed):
                        if not self.final_wipe_groups:
                            break
                        next_group = self.final_wipe_groups.pop(0)
                        for character in next_group:
                            character.animation.activate_scene(character.animation.query_scene("brighten"))
                            self.terminal.set_character_visibility(character, is_visible=True)
                            self.active_characters.add(character)
                else:
                    self.phase = "complete"
            self.update()
            return self.frame
        raise StopIteration

Group

Represents a group of characters.

Source code in terminaltexteffects/effects/effect_beams.py
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
class Group:
    """Represents a group of characters."""

    def __init__(
        self,
        characters: list[tte.EffectCharacter],
        direction: str,
        terminal: tte.Terminal,
        args: BeamsConfig,
    ) -> None:
        """Initialize the Group."""
        self.characters = characters
        self.direction: str = direction
        self.terminal = terminal
        direction_speed_range = {
            "row": (args.beam_row_speed_range[0], args.beam_row_speed_range[1]),
            "column": (args.beam_column_speed_range[0], args.beam_column_speed_range[1]),
        }
        self.speed = random.randint(direction_speed_range[direction][0], direction_speed_range[direction][1]) * 0.1
        self.next_character_counter: float = 0
        if self.direction == "row":
            self.characters.sort(key=lambda character: character.input_coord.column)
        elif self.direction == "column":
            self.characters.sort(key=lambda character: character.input_coord.row)
        if random.choice([True, False]):
            self.characters.reverse()

    def increment_next_character_counter(self) -> None:
        """Increment the counter for the next character."""
        self.next_character_counter += self.speed

    def get_next_character(self) -> tte.EffectCharacter | None:
        """Get the next character in the group.

        If the next character is already active, determined by having an active scene, the active
        scene is reset and None is returned. Otherwise, the next character is returned and the character
        is made visible.

        Returns:
            tte.EffectCharacter | None: The next character if the character or None if the character is
                already active.

        """
        self.next_character_counter -= 1
        next_character = self.characters.pop(0)
        if next_character.animation.active_scene:
            next_character.animation.active_scene.reset_scene()
            return_value = None
        else:
            self.terminal.set_character_visibility(next_character, is_visible=True)
            return_value = next_character
        next_character.animation.activate_scene(next_character.animation.query_scene("beam_" + self.direction))
        return return_value

    def complete(self) -> bool:
        """Check if the group is complete.

        Returns:
            bool: True if the group is complete, False otherwise.

        """
        return not self.characters

__init__(characters, direction, terminal, args)

Initialize the Group.

Source code in terminaltexteffects/effects/effect_beams.py
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
def __init__(
    self,
    characters: list[tte.EffectCharacter],
    direction: str,
    terminal: tte.Terminal,
    args: BeamsConfig,
) -> None:
    """Initialize the Group."""
    self.characters = characters
    self.direction: str = direction
    self.terminal = terminal
    direction_speed_range = {
        "row": (args.beam_row_speed_range[0], args.beam_row_speed_range[1]),
        "column": (args.beam_column_speed_range[0], args.beam_column_speed_range[1]),
    }
    self.speed = random.randint(direction_speed_range[direction][0], direction_speed_range[direction][1]) * 0.1
    self.next_character_counter: float = 0
    if self.direction == "row":
        self.characters.sort(key=lambda character: character.input_coord.column)
    elif self.direction == "column":
        self.characters.sort(key=lambda character: character.input_coord.row)
    if random.choice([True, False]):
        self.characters.reverse()

complete()

Check if the group is complete.

Returns:

Name Type Description
bool bool

True if the group is complete, False otherwise.
Source code in terminaltexteffects/effects/effect_beams.py
304
305
306
307
308
309
310
311
def complete(self) -> bool:
    """Check if the group is complete.

    Returns:
        bool: True if the group is complete, False otherwise.

    """
    return not self.characters

get_next_character()

Get the next character in the group.

If the next character is already active, determined by having an active scene, the active scene is reset and None is returned. Otherwise, the next character is returned and the character is made visible.

Returns:

Type Description
EffectCharacter | None

tte.EffectCharacter | None: The next character if the character or None if the character is already active.
Source code in terminaltexteffects/effects/effect_beams.py
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
def get_next_character(self) -> tte.EffectCharacter | None:
    """Get the next character in the group.

    If the next character is already active, determined by having an active scene, the active
    scene is reset and None is returned. Otherwise, the next character is returned and the character
    is made visible.

    Returns:
        tte.EffectCharacter | None: The next character if the character or None if the character is
            already active.

    """
    self.next_character_counter -= 1
    next_character = self.characters.pop(0)
    if next_character.animation.active_scene:
        next_character.animation.active_scene.reset_scene()
        return_value = None
    else:
        self.terminal.set_character_visibility(next_character, is_visible=True)
        return_value = next_character
    next_character.animation.activate_scene(next_character.animation.query_scene("beam_" + self.direction))
    return return_value

increment_next_character_counter()

Increment the counter for the next character.

Source code in terminaltexteffects/effects/effect_beams.py
277
278
279
def increment_next_character_counter(self) -> None:
    """Increment the counter for the next character."""
    self.next_character_counter += self.speed

__init__(effect)

Initialize the BeamsIterator.

Parameters:

Name Type Description Default
effect Beams

The Beams effect instance.

 required
Source code in terminaltexteffects/effects/effect_beams.py
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
def __init__(self, effect: Beams) -> None:
    """Initialize the BeamsIterator.

    Args:
        effect (Beams): The Beams effect instance.

    """
    super().__init__(effect)
    self.pending_groups: list[BeamsIterator.Group] = []
    self.character_final_color_map: dict[tte.EffectCharacter, tte.ColorPair] = {}
    self.active_groups: list[BeamsIterator.Group] = []
    self.delay = 0
    self.phase = "beams"
    self.final_wipe_groups = self.terminal.get_characters_grouped(
        tte.Terminal.CharacterGroup.DIAGONAL_TOP_LEFT_TO_BOTTOM_RIGHT,
    )
    self.build()

__next__()

Return the next frame in the effect.

Source code in terminaltexteffects/effects/effect_beams.py
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
def __next__(self) -> str:
    """Return the next frame in the effect."""
    if self.phase != "complete" or self.active_characters:
        if self.phase == "beams":
            if not self.delay:
                if self.pending_groups:
                    for _ in range(random.randint(1, 5)):
                        if self.pending_groups:
                            self.active_groups.append(self.pending_groups.pop(0))
                self.delay = self.config.beam_delay
            else:
                self.delay -= 1
            for group in self.active_groups:
                group.increment_next_character_counter()
                if int(group.next_character_counter) > 1:
                    for _ in range(int(group.next_character_counter)):
                        if not group.complete():
                            next_char = group.get_next_character()
                            if next_char:
                                self.active_characters.add(next_char)
            self.active_groups = [group for group in self.active_groups if not group.complete()]
            if not self.pending_groups and not self.active_groups and not self.active_characters:
                self.phase = "final_wipe"
        elif self.phase == "final_wipe":
            if self.final_wipe_groups:
                for _ in range(self.config.final_wipe_speed):
                    if not self.final_wipe_groups:
                        break
                    next_group = self.final_wipe_groups.pop(0)
                    for character in next_group:
                        character.animation.activate_scene(character.animation.query_scene("brighten"))
                        self.terminal.set_character_visibility(character, is_visible=True)
                        self.active_characters.add(character)
            else:
                self.phase = "complete"
        self.update()
        return self.frame
    raise StopIteration

build()

Build the initial state for the Beams effect.

Source code in terminaltexteffects/effects/effect_beams.py
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
def build(self) -> None:
    """Build the initial state for the Beams effect."""
    final_gradient = tte.Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters(outer_fill_chars=True, inner_fill_chars=True):
        if character.is_fill_character:
            self.character_final_color_map[character] = tte.ColorPair(fg="000000")
            continue
        if self.terminal.config.existing_color_handling == "dynamic" and self.preexisting_colors_present:
            fg_color = tte.Color("ffffff")
            bg_color = None
            if character.animation.input_fg_color:
                fg_color = character.animation.input_fg_color
            if character.animation.input_bg_color:
                bg_color = character.animation.input_bg_color
            self.character_final_color_map[character] = tte.ColorPair(fg=fg_color, bg=bg_color)
        else:
            self.character_final_color_map[character] = tte.ColorPair(
                fg=final_gradient_mapping[character.input_coord],
            )

    beam_gradient = tte.Gradient(*self.config.beam_gradient_stops, steps=self.config.beam_gradient_steps)
    groups: list[BeamsIterator.Group] = []
    for row in self.terminal.get_characters_grouped(
        tte.Terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
        outer_fill_chars=True,
        inner_fill_chars=True,
    ):
        groups.append(BeamsIterator.Group(row, "row", self.terminal, self.config))  # noqa: PERF401
    for column in self.terminal.get_characters_grouped(
        tte.Terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
        outer_fill_chars=True,
        inner_fill_chars=True,
    ):
        groups.append(BeamsIterator.Group(column, "column", self.terminal, self.config))  # noqa: PERF401
    for group in groups:
        for character in group.characters:
            beam_row_scn = character.animation.new_scene(scene_id="beam_row")
            beam_column_scn = character.animation.new_scene(scene_id="beam_column")
            brigthen_scn = character.animation.new_scene(scene_id="brighten")
            beam_row_scn.apply_gradient_to_symbols(
                self.config.beam_row_symbols,
                self.config.beam_gradient_frames,
                fg_gradient=beam_gradient,
            )
            beam_column_scn.apply_gradient_to_symbols(
                self.config.beam_column_symbols,
                self.config.beam_gradient_frames,
                fg_gradient=beam_gradient,
            )
            fg_fade_gradient = bg_fade_gradient = fg_brighten_gradient = bg_brighten_gradient = None
            char_fg_color = self.character_final_color_map[character].fg_color
            char_bg_color = self.character_final_color_map[character].bg_color
            if char_fg_color:
                faded_fg_color = character.animation.adjust_color_brightness(char_fg_color, 0.3)
                fg_fade_gradient = tte.Gradient(char_fg_color, faded_fg_color, steps=10)
                fg_brighten_gradient = tte.Gradient(faded_fg_color, char_fg_color, steps=10)
            if char_bg_color:
                faded_bg_color = character.animation.adjust_color_brightness(char_bg_color, 0.3)
                bg_fade_gradient = tte.Gradient(char_bg_color, faded_bg_color, steps=10)
                bg_brighten_gradient = tte.Gradient(faded_bg_color, char_bg_color, steps=10)

            beam_row_scn.apply_gradient_to_symbols(
                character.input_symbol,
                5,
                fg_gradient=fg_fade_gradient,
                bg_gradient=bg_fade_gradient,
            )
            beam_column_scn.apply_gradient_to_symbols(
                character.input_symbol,
                5,
                fg_gradient=fg_fade_gradient,
                bg_gradient=bg_fade_gradient,
            )
            brigthen_scn.apply_gradient_to_symbols(
                character.input_symbol,
                self.config.final_gradient_frames,
                fg_gradient=fg_brighten_gradient,
                bg_gradient=bg_brighten_gradient,
            )

    self.pending_groups = groups
    random.shuffle(self.pending_groups)

get_effect_and_args()

Return the Beams effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_beams.py
21
22
23
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Return the Beams effect class and its configuration class."""
    return Beams, BeamsConfig
