Matrix

Demo

Quick Start

matrix.py
from terminaltexteffects.effects.effect_matrix import Matrix

effect = Matrix("YourTextHere\n" * 10)
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Matrix digital rain effect.

Classes:

Name Description
Matrix

Matrix digital rain effect.
MatrixConfig

Configuration for the Matrix effect.
MatrixIterator

Iterator for the Matrix effect. Does not normally need to be called directly.

Matrix

Bases: BaseEffect[MatrixConfig]

Matrix digital rain effect.

Attributes:

Name Type Description
effect_config MatrixConfig

Configuration for the Matrix effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_matrix.py
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
class Matrix(BaseEffect[MatrixConfig]):
    """Matrix digital rain effect.

    Attributes:
        effect_config (MatrixConfig): Configuration for the Matrix effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[MatrixConfig]:
        return MatrixConfig

    @property
    def _iterator_cls(self) -> type[MatrixIterator]:
        return MatrixIterator

MatrixConfig dataclass

Bases: ArgsDataClass

Configuration for the Matrix effect.

Attributes:

Name Type Description
highlight_color Color

Color for the bottom of the rain column.
rain_color_gradient tuple[Color, ...]

Tuple of colors for the rain gradient. If only one color is " "provided, the characters will be displayed in that color.
rain_symbols tuple[str, ...]

Tuple of symbols to use for the rain.
rain_fall_delay_range tuple[int, int]

Speed of the falling rain as determined by the delay between rows. " "Actual delay is randomly selected from the range.
rain_column_delay_range tuple[int, int]

Range of frames to wait between adding new rain columns.
rain_time int

Time, in seconds, to display the rain effect before transitioning to the input text.
symbol_swap_chance float

Chance of swapping a character's symbol on each tick.
color_swap_chance float

Chance of swapping a character's color on each tick.
resolve_delay int

Number of frames to wait between resolving the next group of characters. This is used " "to adjust the speed of the final resolve phase.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color " "is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Int or Tuple of ints for the number of gradient steps to use. " "More steps will create a smoother and longer gradient animation.
final_gradient_frames int

Number of frames to display each gradient step. Increase to slow down the " "gradient animation.
final_gradient_direction Direction

Direction of the final gradient.
Source code in terminaltexteffects/effects/effect_matrix.py
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
@argclass(
    name="matrix",
    help="Matrix digital rain effect.",
    description="matrix | Matrix digital rain effect.",
    epilog=(
        "Example: tte matrix --rain-color-gradient 92be92 185318 --rain-symbols 2 5 9 8 Z : . = + - ¦ _ "
        "--rain-fall-delay-range 8-25 --rain-column-delay-range 5-15 --rain-time 15 --symbol-swap-chance 0.005 "
        "--color-swap-chance 0.001 --resolve-delay 5 --final-gradient-stops 389c38 --final-gradient-steps 12 "
        "--final-gradient-frames 5 --final-gradient-direction vertical --highlight-color dbffdb"
    ),
)
@dataclass
class MatrixConfig(ArgsDataClass):
    """Configuration for the Matrix effect.

    Attributes:
        highlight_color (Color): Color for the bottom of the rain column.
        rain_color_gradient (tuple[Color, ...]): Tuple of colors for the rain gradient. If only one color is "
            "provided, the characters will be displayed in that color.
        rain_symbols (tuple[str, ...]): Tuple of symbols to use for the rain.
        rain_fall_delay_range (tuple[int, int]): Speed of the falling rain as determined by the delay between rows. "
            "Actual delay is randomly selected from the range.
        rain_column_delay_range (tuple[int, int]): Range of frames to wait between adding new rain columns.
        rain_time (int): Time, in seconds, to display the rain effect before transitioning to the input text.
        symbol_swap_chance (float): Chance of swapping a character's symbol on each tick.
        color_swap_chance (float): Chance of swapping a character's color on each tick.
        resolve_delay (int): Number of frames to wait between resolving the next group of characters. This is used "
            "to adjust the speed of the final resolve phase.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color "
            "is provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Int or Tuple of ints for the number of gradient steps to use. "
            "More steps will create a smoother and longer gradient animation.
        final_gradient_frames (int): Number of frames to display each gradient step. Increase to slow down the "
            "gradient animation.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.

    """

    highlight_color: Color = ArgField(
        cmd_name=["--highlight-color"],
        type_parser=argvalidators.ColorArg.type_parser,
        default=Color("dbffdb"),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Color for the bottom of the rain column.",
    )  # type: ignore[assignment]
    "Color : Color for the bottom of the rain column."

    rain_color_gradient: tuple[Color, ...] = ArgField(
        cmd_name=["--rain-color-gradient"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("92be92"), Color("185318")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the rain gradient. Colors are selected from the "
        "gradient randomly. If only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the rain gradient. If only one color is provided, the characters "
        "will be displayed in that color."
    )

    rain_symbols: tuple[str, ...] = ArgField(
        cmd_name=["--rain-symbols"],
        nargs="+",
        type_parser=argvalidators.Symbol.type_parser,
        default=MATRIX_SYMBOLS_COMMON + MATRIX_SYMBOLS_KATA,
        metavar=argvalidators.Symbol.METAVAR,
        help="Space separated, unquoted, list of symbols to use for the rain.",
    )  # type: ignore[assignment]
    "tuple[str, ...] : Tuple of symbols to use for the rain."

    rain_fall_delay_range: tuple[int, int] = ArgField(
        cmd_name=["--rain-fall-delay-range"],
        type_parser=argvalidators.PositiveIntRange.type_parser,
        default=(3, 25),
        metavar=argvalidators.PositiveIntRange.METAVAR,
        help="Range for the speed of the falling rain as determined by the delay between rows. Actual delay is "
        "randomly selected from the range.",
    )  # type: ignore[assignment]
    (
        "tuple[int, int] : Speed of the falling rain as determined by the delay between rows. Actual delay is "
        "randomly selected from the range."
    )

    rain_column_delay_range: tuple[int, int] = ArgField(
        cmd_name=["--rain-column-delay-range"],
        type_parser=argvalidators.PositiveIntRange.type_parser,
        default=(5, 15),
        metavar=argvalidators.PositiveIntRange.METAVAR,
        help="Range of frames to wait between adding new rain columns.",
    )  # type: ignore[assignment]
    "tuple[int, int] : Range of frames to wait between adding new rain columns."

    rain_time: int = ArgField(
        cmd_name="--rain-time",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=15,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Time, in seconds, to display the rain effect before transitioning to the input text.",
    )  # type: ignore[assignment]
    "int : Time, in seconds, to display the rain effect before transitioning to the input text."

    symbol_swap_chance: float = ArgField(
        cmd_name="--symbol-swap-chance",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.005,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Chance of swapping a character's symbol on each tick.",
    )  # type: ignore[assignment]
    "float : Chance of swapping a character's symbol on each tick."

    color_swap_chance: float = ArgField(
        cmd_name="--color-swap-chance",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.001,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Chance of swapping a character's color on each tick.",
    )  # type: ignore[assignment]
    "float : Chance of swapping a character's color on each tick."

    resolve_delay: int = ArgField(
        cmd_name="--resolve-delay",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=5,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of frames to wait between resolving the next group of characters. "
        "This is used to adjust the speed of the final resolve phase.",
    )  # type: ignore[assignment]
    (
        "int : Number of frames to wait between resolving the next group of characters. This is used to "
        "adjust the speed of the final resolve phase."
    )

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--final-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("92be92"), Color("336b33")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If "
        "only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--final-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a "
        "smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will "
        "create a smoother and longer gradient animation."
    )

    final_gradient_frames: int = ArgField(
        cmd_name="--final-gradient-frames",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=5,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of frames to display each gradient step. Increase to slow down the gradient animation.",
    )  # type: ignore[assignment]
    "int : Number of frames to display each gradient step. Increase to slow down the gradient animation."

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.RADIAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the final gradient."

    @classmethod
    def get_effect_class(cls) -> type[Matrix]:
        """Get the effect class associated with this configuration."""
        return Matrix

color_swap_chance = ArgField(cmd_name='--color-swap-chance', type_parser=argvalidators.PositiveFloat.type_parser, default=0.001, metavar=argvalidators.PositiveFloat.METAVAR, help="Chance of swapping a character's color on each tick.") class-attribute instance-attribute

float : Chance of swapping a character's color on each tick.

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.RADIAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_frames = ArgField(cmd_name='--final-gradient-frames', type_parser=argvalidators.PositiveInt.type_parser, default=5, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to display each gradient step. Increase to slow down the gradient animation.') class-attribute instance-attribute

int : Number of frames to display each gradient step. Increase to slow down the gradient animation.

final_gradient_steps = ArgField(cmd_name='--final-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

final_gradient_stops = ArgField(cmd_name=['--final-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('92be92'), Color('336b33')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

highlight_color = ArgField(cmd_name=['--highlight-color'], type_parser=argvalidators.ColorArg.type_parser, default=Color('dbffdb'), metavar=argvalidators.ColorArg.METAVAR, help='Color for the bottom of the rain column.') class-attribute instance-attribute

Color : Color for the bottom of the rain column.

rain_color_gradient = ArgField(cmd_name=['--rain-color-gradient'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('92be92'), Color('185318')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the rain gradient. Colors are selected from the gradient randomly. If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the rain gradient. If only one color is provided, the characters will be displayed in that color.

rain_column_delay_range = ArgField(cmd_name=['--rain-column-delay-range'], type_parser=argvalidators.PositiveIntRange.type_parser, default=(5, 15), metavar=argvalidators.PositiveIntRange.METAVAR, help='Range of frames to wait between adding new rain columns.') class-attribute instance-attribute

tuple[int, int] : Range of frames to wait between adding new rain columns.

rain_fall_delay_range = ArgField(cmd_name=['--rain-fall-delay-range'], type_parser=argvalidators.PositiveIntRange.type_parser, default=(3, 25), metavar=argvalidators.PositiveIntRange.METAVAR, help='Range for the speed of the falling rain as determined by the delay between rows. Actual delay is randomly selected from the range.') class-attribute instance-attribute

tuple[int, int] : Speed of the falling rain as determined by the delay between rows. Actual delay is randomly selected from the range.

rain_symbols = ArgField(cmd_name=['--rain-symbols'], nargs='+', type_parser=argvalidators.Symbol.type_parser, default=MATRIX_SYMBOLS_COMMON + MATRIX_SYMBOLS_KATA, metavar=argvalidators.Symbol.METAVAR, help='Space separated, unquoted, list of symbols to use for the rain.') class-attribute instance-attribute

tuple[str, ...] : Tuple of symbols to use for the rain.

rain_time = ArgField(cmd_name='--rain-time', type_parser=argvalidators.PositiveInt.type_parser, default=15, metavar=argvalidators.PositiveInt.METAVAR, help='Time, in seconds, to display the rain effect before transitioning to the input text.') class-attribute instance-attribute

int : Time, in seconds, to display the rain effect before transitioning to the input text.

resolve_delay = ArgField(cmd_name='--resolve-delay', type_parser=argvalidators.PositiveInt.type_parser, default=5, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to wait between resolving the next group of characters. This is used to adjust the speed of the final resolve phase.') class-attribute instance-attribute

int : Number of frames to wait between resolving the next group of characters. This is used to adjust the speed of the final resolve phase.

symbol_swap_chance = ArgField(cmd_name='--symbol-swap-chance', type_parser=argvalidators.PositiveFloat.type_parser, default=0.005, metavar=argvalidators.PositiveFloat.METAVAR, help="Chance of swapping a character's symbol on each tick.") class-attribute instance-attribute

float : Chance of swapping a character's symbol on each tick.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_matrix.py
261
262
263
264
@classmethod
def get_effect_class(cls) -> type[Matrix]:
    """Get the effect class associated with this configuration."""
    return Matrix

MatrixIterator

Bases: BaseEffectIterator[MatrixConfig]

Iterator for the Matrix effect.

Source code in terminaltexteffects/effects/effect_matrix.py
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
class MatrixIterator(BaseEffectIterator[MatrixConfig]):
    """Iterator for the Matrix effect."""

    class RainColumn:
        """Rain column for the Matrix effect."""

        def __init__(
            self,
            characters: list[EffectCharacter],
            terminal: Terminal,
            config: MatrixConfig,
            rain_colors: Gradient,
        ) -> None:
            """Initialize the rain column."""
            self.terminal = terminal
            self.config = config
            self.characters: list[EffectCharacter] = characters
            self.pending_characters: list[EffectCharacter] = []
            self.matrix_symbols: tuple[str, ...] = config.rain_symbols
            self.rain_colors = rain_colors
            self.column_drop_chance = 0.08
            self.setup_column("rain")

        def setup_column(self, phase: str) -> None:
            """Set up the rain column for the specified phase."""
            self.pending_characters.clear()
            self.phase = phase
            for character in self.characters:
                self.terminal.set_character_visibility(character, is_visible=False)
                self.pending_characters.append(character)
                character.motion.current_coord = character.input_coord
            self.visible_characters: list[EffectCharacter] = []
            if self.phase == "fill":
                self.base_rain_fall_delay = random.randint(
                    max(self.config.rain_fall_delay_range[0] // 3, 1),
                    max(self.config.rain_fall_delay_range[1] // 3, 1),
                )
            else:
                self.base_rain_fall_delay = random.randint(
                    self.config.rain_fall_delay_range[0],
                    self.config.rain_fall_delay_range[1],
                )
            self.active_rain_fall_delay = 0
            if self.phase == "rain":
                self.length = random.randint(max(1, int(len(self.characters) * 0.1)), len(self.characters))
            else:
                self.length = len(self.characters)
            self.hold_time = 0
            if self.length == len(self.characters):
                self.hold_time = random.randint(20, 45)

        def trim_column(self) -> None:
            """Trim the rain column."""
            if not self.visible_characters:
                return
            popped_char = self.visible_characters.pop(0)
            self.terminal.set_character_visibility(popped_char, is_visible=False)
            if len(self.visible_characters) > 1:
                self.fade_last_character()

        def drop_column(self) -> None:
            """Drop the rain column."""
            out_of_canvas = []
            for character in self.visible_characters:
                character.motion.current_coord = Coord(
                    character.motion.current_coord.column,
                    character.motion.current_coord.row - 1,
                )
                if character.motion.current_coord.row < self.terminal.canvas.bottom:
                    self.terminal.set_character_visibility(character, is_visible=False)
                    out_of_canvas.append(character)
            self.visible_characters = [char for char in self.visible_characters if char not in out_of_canvas]

        def fade_last_character(self) -> None:
            """Fade the last character in the rain column."""
            darker_color = Animation.adjust_color_brightness(random.choice(self.rain_colors[-3:]), 0.65)  # type: ignore[arg-type]
            self.visible_characters[0].animation.set_appearance(
                self.visible_characters[0].animation.current_character_visual.symbol,
                colors=ColorPair(fg=darker_color),
            )

        def resolve_char(self) -> EffectCharacter:
            """Resolve a character in the rain column.

            Returns:
                EffectCharacter: The resolved character.

            """
            return self.visible_characters.pop(random.randint(0, len(self.visible_characters) - 1))

        def tick(self) -> None:
            """Advance the rain column by one tick."""
            if not self.active_rain_fall_delay:
                if self.pending_characters:
                    next_char = self.pending_characters.pop(0)
                    next_char.animation.set_appearance(
                        random.choice(self.matrix_symbols),
                        colors=ColorPair(fg=self.config.highlight_color),
                    )
                    previous_character = self.visible_characters[-1] if self.visible_characters else None
                    # if there is a previous character, remove the highlight
                    if previous_character:
                        previous_character.animation.set_appearance(
                            previous_character.animation.current_character_visual.symbol,
                            colors=ColorPair(
                                fg=random.choice(self.rain_colors),
                            ),
                        )
                    self.terminal.set_character_visibility(next_char, is_visible=True)
                    self.visible_characters.append(next_char)

                # if no pending characters, but still visible characters, trim the column
                # unless the column is the full height of the canvas, then respect the hold
                # time before trimming
                elif self.visible_characters:
                    # adjust the bottom character color to remove the lightlight.
                    # always do this on the first hold frame, then
                    # randomly adjust the bottom character's color
                    # this is separately handled from the rest to prevent the
                    # highlight color from being replaced before appropriate
                    if (
                        self.visible_characters[-1].animation.current_character_visual.colors
                        and self.visible_characters[-1].animation.current_character_visual.colors.fg_color
                        == self.config.highlight_color
                    ):
                        self.visible_characters[-1].animation.set_appearance(
                            self.visible_characters[-1].animation.current_character_visual.symbol,
                            colors=ColorPair(fg=random.choice(self.rain_colors)),
                        )

                    if self.hold_time:
                        self.hold_time -= 1
                    elif self.phase == "rain":
                        if random.random() < self.column_drop_chance:
                            self.drop_column()
                        self.trim_column()

                # if the column is longer than the preset length while still adding characters, trim it
                if len(self.visible_characters) > self.length:
                    self.trim_column()
                self.active_rain_fall_delay = self.base_rain_fall_delay

            else:
                self.active_rain_fall_delay -= 1

            # randomly change the symbol and/or color of the characters
            next_color: Color | None
            for character in self.visible_characters:
                if random.random() < self.config.symbol_swap_chance:
                    next_symbol = random.choice(self.matrix_symbols)
                else:
                    next_symbol = character.animation.current_character_visual.symbol
                if random.random() < self.config.color_swap_chance:
                    next_color = random.choice(self.rain_colors)
                elif character.animation.current_character_visual.colors:
                    next_color = character.animation.current_character_visual.colors.fg_color
                else:
                    next_color = None
                character.animation.set_appearance(next_symbol, colors=ColorPair(fg=next_color))

    def __init__(self, effect: Matrix) -> None:
        """Initialize the Matrix effect iterator."""
        super().__init__(effect)
        self.pending_columns: list[MatrixIterator.RainColumn] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.active_columns: list[MatrixIterator.RainColumn] = []
        self.full_columns: list[MatrixIterator.RainColumn] = []
        self.rain_colors = Gradient(*self.config.rain_color_gradient, steps=6)
        self.column_delay = 0
        self.resolve_delay = self.config.resolve_delay
        self.final_frame_shown = False
        self.rain_complete = False
        self.phase = "rain"
        self.build()
        self.rain_start = time.time()

    def build(self) -> None:
        """Build the initial state of the effect."""
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters():
            resolve_scn = character.animation.new_scene(scene_id="resolve")
            for color in Gradient(self.config.highlight_color, final_gradient_mapping[character.input_coord], steps=8):
                resolve_scn.add_frame(
                    character.input_symbol,
                    self.config.final_gradient_frames,
                    colors=ColorPair(fg=color),
                )

        for column_chars in self.terminal.get_characters_grouped(
            self.terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
            outer_fill_chars=True,
            inner_fill_chars=True,
        ):
            column_chars.reverse()
            self.pending_columns.append(
                MatrixIterator.RainColumn(column_chars, self.terminal, self.config, self.rain_colors),
            )
        random.shuffle(self.pending_columns)

    def __next__(self) -> str:  # noqa: PLR0915
        """Return the next frame in the animation."""
        if self.phase in ("rain", "fill"):
            if not self.column_delay:
                if self.phase == "rain":
                    for _ in range(random.randint(1, 3)):
                        if self.pending_columns:
                            self.active_columns.append(self.pending_columns.pop(0))
                else:
                    while self.pending_columns:
                        self.active_columns.append(self.pending_columns.pop(0))
                if self.phase == "rain":
                    self.column_delay = random.randint(
                        self.config.rain_column_delay_range[0],
                        self.config.rain_column_delay_range[1],
                    )
                else:
                    self.column_delay = 1
            else:
                self.column_delay -= 1
            for column in self.active_columns:
                column.tick()

                if not column.pending_characters:
                    if column.phase == "fill" and column not in self.full_columns:
                        self.full_columns.append(column)
                    elif not column.visible_characters:
                        column.setup_column(self.phase)
                        self.pending_columns.append(column)

            self.active_columns = [column for column in self.active_columns if column.visible_characters]
            if (
                self.phase == "fill"
                and not self.pending_columns
                and all((not column.pending_characters and column.phase == "fill") for column in self.active_columns)
            ):
                self.phase = "resolve"
                self.active_columns.clear()

            if (
                self.phase == "rain"
                and self.config.rain_time > 0
                and time.time() - self.rain_start > self.config.rain_time
            ):
                self.rain_complete = True
                self.phase = "fill"
                for column in self.active_columns:
                    column.hold_time = 0
                    column.column_drop_chance = 1
                for column in self.pending_columns:
                    column.setup_column(self.phase)

        elif self.phase == "resolve":
            for column in self.full_columns:
                column.tick()
                if column.visible_characters:
                    if not self.resolve_delay:
                        for _ in range(random.randint(1, 4)):
                            if column.visible_characters:
                                next_char = column.resolve_char()
                                if next_char.input_symbol != " ":
                                    next_char.animation.activate_scene(next_char.animation.query_scene("resolve"))
                                    self.active_characters.add(next_char)
                                else:
                                    self.terminal.set_character_visibility(next_char, is_visible=False)
                        self.resolve_delay = self.config.resolve_delay
                    else:
                        self.resolve_delay -= 1

            self.full_columns = [column for column in self.full_columns if column.visible_characters]

        if (
            self.full_columns
            or self.active_columns
            or self.active_characters
            or self.pending_columns
            or not self.rain_complete
        ):
            self.update()
            return self.frame
        if not self.final_frame_shown:
            self.final_frame_shown = True
            self.update()
            return self.frame
        raise StopIteration

RainColumn

Rain column for the Matrix effect.

Source code in terminaltexteffects/effects/effect_matrix.py
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
class RainColumn:
    """Rain column for the Matrix effect."""

    def __init__(
        self,
        characters: list[EffectCharacter],
        terminal: Terminal,
        config: MatrixConfig,
        rain_colors: Gradient,
    ) -> None:
        """Initialize the rain column."""
        self.terminal = terminal
        self.config = config
        self.characters: list[EffectCharacter] = characters
        self.pending_characters: list[EffectCharacter] = []
        self.matrix_symbols: tuple[str, ...] = config.rain_symbols
        self.rain_colors = rain_colors
        self.column_drop_chance = 0.08
        self.setup_column("rain")

    def setup_column(self, phase: str) -> None:
        """Set up the rain column for the specified phase."""
        self.pending_characters.clear()
        self.phase = phase
        for character in self.characters:
            self.terminal.set_character_visibility(character, is_visible=False)
            self.pending_characters.append(character)
            character.motion.current_coord = character.input_coord
        self.visible_characters: list[EffectCharacter] = []
        if self.phase == "fill":
            self.base_rain_fall_delay = random.randint(
                max(self.config.rain_fall_delay_range[0] // 3, 1),
                max(self.config.rain_fall_delay_range[1] // 3, 1),
            )
        else:
            self.base_rain_fall_delay = random.randint(
                self.config.rain_fall_delay_range[0],
                self.config.rain_fall_delay_range[1],
            )
        self.active_rain_fall_delay = 0
        if self.phase == "rain":
            self.length = random.randint(max(1, int(len(self.characters) * 0.1)), len(self.characters))
        else:
            self.length = len(self.characters)
        self.hold_time = 0
        if self.length == len(self.characters):
            self.hold_time = random.randint(20, 45)

    def trim_column(self) -> None:
        """Trim the rain column."""
        if not self.visible_characters:
            return
        popped_char = self.visible_characters.pop(0)
        self.terminal.set_character_visibility(popped_char, is_visible=False)
        if len(self.visible_characters) > 1:
            self.fade_last_character()

    def drop_column(self) -> None:
        """Drop the rain column."""
        out_of_canvas = []
        for character in self.visible_characters:
            character.motion.current_coord = Coord(
                character.motion.current_coord.column,
                character.motion.current_coord.row - 1,
            )
            if character.motion.current_coord.row < self.terminal.canvas.bottom:
                self.terminal.set_character_visibility(character, is_visible=False)
                out_of_canvas.append(character)
        self.visible_characters = [char for char in self.visible_characters if char not in out_of_canvas]

    def fade_last_character(self) -> None:
        """Fade the last character in the rain column."""
        darker_color = Animation.adjust_color_brightness(random.choice(self.rain_colors[-3:]), 0.65)  # type: ignore[arg-type]
        self.visible_characters[0].animation.set_appearance(
            self.visible_characters[0].animation.current_character_visual.symbol,
            colors=ColorPair(fg=darker_color),
        )

    def resolve_char(self) -> EffectCharacter:
        """Resolve a character in the rain column.

        Returns:
            EffectCharacter: The resolved character.

        """
        return self.visible_characters.pop(random.randint(0, len(self.visible_characters) - 1))

    def tick(self) -> None:
        """Advance the rain column by one tick."""
        if not self.active_rain_fall_delay:
            if self.pending_characters:
                next_char = self.pending_characters.pop(0)
                next_char.animation.set_appearance(
                    random.choice(self.matrix_symbols),
                    colors=ColorPair(fg=self.config.highlight_color),
                )
                previous_character = self.visible_characters[-1] if self.visible_characters else None
                # if there is a previous character, remove the highlight
                if previous_character:
                    previous_character.animation.set_appearance(
                        previous_character.animation.current_character_visual.symbol,
                        colors=ColorPair(
                            fg=random.choice(self.rain_colors),
                        ),
                    )
                self.terminal.set_character_visibility(next_char, is_visible=True)
                self.visible_characters.append(next_char)

            # if no pending characters, but still visible characters, trim the column
            # unless the column is the full height of the canvas, then respect the hold
            # time before trimming
            elif self.visible_characters:
                # adjust the bottom character color to remove the lightlight.
                # always do this on the first hold frame, then
                # randomly adjust the bottom character's color
                # this is separately handled from the rest to prevent the
                # highlight color from being replaced before appropriate
                if (
                    self.visible_characters[-1].animation.current_character_visual.colors
                    and self.visible_characters[-1].animation.current_character_visual.colors.fg_color
                    == self.config.highlight_color
                ):
                    self.visible_characters[-1].animation.set_appearance(
                        self.visible_characters[-1].animation.current_character_visual.symbol,
                        colors=ColorPair(fg=random.choice(self.rain_colors)),
                    )

                if self.hold_time:
                    self.hold_time -= 1
                elif self.phase == "rain":
                    if random.random() < self.column_drop_chance:
                        self.drop_column()
                    self.trim_column()

            # if the column is longer than the preset length while still adding characters, trim it
            if len(self.visible_characters) > self.length:
                self.trim_column()
            self.active_rain_fall_delay = self.base_rain_fall_delay

        else:
            self.active_rain_fall_delay -= 1

        # randomly change the symbol and/or color of the characters
        next_color: Color | None
        for character in self.visible_characters:
            if random.random() < self.config.symbol_swap_chance:
                next_symbol = random.choice(self.matrix_symbols)
            else:
                next_symbol = character.animation.current_character_visual.symbol
            if random.random() < self.config.color_swap_chance:
                next_color = random.choice(self.rain_colors)
            elif character.animation.current_character_visual.colors:
                next_color = character.animation.current_character_visual.colors.fg_color
            else:
                next_color = None
            character.animation.set_appearance(next_symbol, colors=ColorPair(fg=next_color))

__init__(characters, terminal, config, rain_colors)

Initialize the rain column.

Source code in terminaltexteffects/effects/effect_matrix.py
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
def __init__(
    self,
    characters: list[EffectCharacter],
    terminal: Terminal,
    config: MatrixConfig,
    rain_colors: Gradient,
) -> None:
    """Initialize the rain column."""
    self.terminal = terminal
    self.config = config
    self.characters: list[EffectCharacter] = characters
    self.pending_characters: list[EffectCharacter] = []
    self.matrix_symbols: tuple[str, ...] = config.rain_symbols
    self.rain_colors = rain_colors
    self.column_drop_chance = 0.08
    self.setup_column("rain")

drop_column()

Drop the rain column.

Source code in terminaltexteffects/effects/effect_matrix.py
327
328
329
330
331
332
333
334
335
336
337
338
def drop_column(self) -> None:
    """Drop the rain column."""
    out_of_canvas = []
    for character in self.visible_characters:
        character.motion.current_coord = Coord(
            character.motion.current_coord.column,
            character.motion.current_coord.row - 1,
        )
        if character.motion.current_coord.row < self.terminal.canvas.bottom:
            self.terminal.set_character_visibility(character, is_visible=False)
            out_of_canvas.append(character)
    self.visible_characters = [char for char in self.visible_characters if char not in out_of_canvas]

fade_last_character()

Fade the last character in the rain column.

Source code in terminaltexteffects/effects/effect_matrix.py
340
341
342
343
344
345
346
def fade_last_character(self) -> None:
    """Fade the last character in the rain column."""
    darker_color = Animation.adjust_color_brightness(random.choice(self.rain_colors[-3:]), 0.65)  # type: ignore[arg-type]
    self.visible_characters[0].animation.set_appearance(
        self.visible_characters[0].animation.current_character_visual.symbol,
        colors=ColorPair(fg=darker_color),
    )

resolve_char()

Resolve a character in the rain column.

Returns:

Name Type Description
EffectCharacter EffectCharacter

The resolved character.
Source code in terminaltexteffects/effects/effect_matrix.py
348
349
350
351
352
353
354
355
def resolve_char(self) -> EffectCharacter:
    """Resolve a character in the rain column.

    Returns:
        EffectCharacter: The resolved character.

    """
    return self.visible_characters.pop(random.randint(0, len(self.visible_characters) - 1))

setup_column(phase)

Set up the rain column for the specified phase.

Source code in terminaltexteffects/effects/effect_matrix.py
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
def setup_column(self, phase: str) -> None:
    """Set up the rain column for the specified phase."""
    self.pending_characters.clear()
    self.phase = phase
    for character in self.characters:
        self.terminal.set_character_visibility(character, is_visible=False)
        self.pending_characters.append(character)
        character.motion.current_coord = character.input_coord
    self.visible_characters: list[EffectCharacter] = []
    if self.phase == "fill":
        self.base_rain_fall_delay = random.randint(
            max(self.config.rain_fall_delay_range[0] // 3, 1),
            max(self.config.rain_fall_delay_range[1] // 3, 1),
        )
    else:
        self.base_rain_fall_delay = random.randint(
            self.config.rain_fall_delay_range[0],
            self.config.rain_fall_delay_range[1],
        )
    self.active_rain_fall_delay = 0
    if self.phase == "rain":
        self.length = random.randint(max(1, int(len(self.characters) * 0.1)), len(self.characters))
    else:
        self.length = len(self.characters)
    self.hold_time = 0
    if self.length == len(self.characters):
        self.hold_time = random.randint(20, 45)

tick()

Advance the rain column by one tick.

Source code in terminaltexteffects/effects/effect_matrix.py
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
def tick(self) -> None:
    """Advance the rain column by one tick."""
    if not self.active_rain_fall_delay:
        if self.pending_characters:
            next_char = self.pending_characters.pop(0)
            next_char.animation.set_appearance(
                random.choice(self.matrix_symbols),
                colors=ColorPair(fg=self.config.highlight_color),
            )
            previous_character = self.visible_characters[-1] if self.visible_characters else None
            # if there is a previous character, remove the highlight
            if previous_character:
                previous_character.animation.set_appearance(
                    previous_character.animation.current_character_visual.symbol,
                    colors=ColorPair(
                        fg=random.choice(self.rain_colors),
                    ),
                )
            self.terminal.set_character_visibility(next_char, is_visible=True)
            self.visible_characters.append(next_char)

        # if no pending characters, but still visible characters, trim the column
        # unless the column is the full height of the canvas, then respect the hold
        # time before trimming
        elif self.visible_characters:
            # adjust the bottom character color to remove the lightlight.
            # always do this on the first hold frame, then
            # randomly adjust the bottom character's color
            # this is separately handled from the rest to prevent the
            # highlight color from being replaced before appropriate
            if (
                self.visible_characters[-1].animation.current_character_visual.colors
                and self.visible_characters[-1].animation.current_character_visual.colors.fg_color
                == self.config.highlight_color
            ):
                self.visible_characters[-1].animation.set_appearance(
                    self.visible_characters[-1].animation.current_character_visual.symbol,
                    colors=ColorPair(fg=random.choice(self.rain_colors)),
                )

            if self.hold_time:
                self.hold_time -= 1
            elif self.phase == "rain":
                if random.random() < self.column_drop_chance:
                    self.drop_column()
                self.trim_column()

        # if the column is longer than the preset length while still adding characters, trim it
        if len(self.visible_characters) > self.length:
            self.trim_column()
        self.active_rain_fall_delay = self.base_rain_fall_delay

    else:
        self.active_rain_fall_delay -= 1

    # randomly change the symbol and/or color of the characters
    next_color: Color | None
    for character in self.visible_characters:
        if random.random() < self.config.symbol_swap_chance:
            next_symbol = random.choice(self.matrix_symbols)
        else:
            next_symbol = character.animation.current_character_visual.symbol
        if random.random() < self.config.color_swap_chance:
            next_color = random.choice(self.rain_colors)
        elif character.animation.current_character_visual.colors:
            next_color = character.animation.current_character_visual.colors.fg_color
        else:
            next_color = None
        character.animation.set_appearance(next_symbol, colors=ColorPair(fg=next_color))

trim_column()

Trim the rain column.

Source code in terminaltexteffects/effects/effect_matrix.py
318
319
320
321
322
323
324
325
def trim_column(self) -> None:
    """Trim the rain column."""
    if not self.visible_characters:
        return
    popped_char = self.visible_characters.pop(0)
    self.terminal.set_character_visibility(popped_char, is_visible=False)
    if len(self.visible_characters) > 1:
        self.fade_last_character()

__init__(effect)

Initialize the Matrix effect iterator.

Source code in terminaltexteffects/effects/effect_matrix.py
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
def __init__(self, effect: Matrix) -> None:
    """Initialize the Matrix effect iterator."""
    super().__init__(effect)
    self.pending_columns: list[MatrixIterator.RainColumn] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.active_columns: list[MatrixIterator.RainColumn] = []
    self.full_columns: list[MatrixIterator.RainColumn] = []
    self.rain_colors = Gradient(*self.config.rain_color_gradient, steps=6)
    self.column_delay = 0
    self.resolve_delay = self.config.resolve_delay
    self.final_frame_shown = False
    self.rain_complete = False
    self.phase = "rain"
    self.build()
    self.rain_start = time.time()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_matrix.py
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
def __next__(self) -> str:  # noqa: PLR0915
    """Return the next frame in the animation."""
    if self.phase in ("rain", "fill"):
        if not self.column_delay:
            if self.phase == "rain":
                for _ in range(random.randint(1, 3)):
                    if self.pending_columns:
                        self.active_columns.append(self.pending_columns.pop(0))
            else:
                while self.pending_columns:
                    self.active_columns.append(self.pending_columns.pop(0))
            if self.phase == "rain":
                self.column_delay = random.randint(
                    self.config.rain_column_delay_range[0],
                    self.config.rain_column_delay_range[1],
                )
            else:
                self.column_delay = 1
        else:
            self.column_delay -= 1
        for column in self.active_columns:
            column.tick()

            if not column.pending_characters:
                if column.phase == "fill" and column not in self.full_columns:
                    self.full_columns.append(column)
                elif not column.visible_characters:
                    column.setup_column(self.phase)
                    self.pending_columns.append(column)

        self.active_columns = [column for column in self.active_columns if column.visible_characters]
        if (
            self.phase == "fill"
            and not self.pending_columns
            and all((not column.pending_characters and column.phase == "fill") for column in self.active_columns)
        ):
            self.phase = "resolve"
            self.active_columns.clear()

        if (
            self.phase == "rain"
            and self.config.rain_time > 0
            and time.time() - self.rain_start > self.config.rain_time
        ):
            self.rain_complete = True
            self.phase = "fill"
            for column in self.active_columns:
                column.hold_time = 0
                column.column_drop_chance = 1
            for column in self.pending_columns:
                column.setup_column(self.phase)

    elif self.phase == "resolve":
        for column in self.full_columns:
            column.tick()
            if column.visible_characters:
                if not self.resolve_delay:
                    for _ in range(random.randint(1, 4)):
                        if column.visible_characters:
                            next_char = column.resolve_char()
                            if next_char.input_symbol != " ":
                                next_char.animation.activate_scene(next_char.animation.query_scene("resolve"))
                                self.active_characters.add(next_char)
                            else:
                                self.terminal.set_character_visibility(next_char, is_visible=False)
                    self.resolve_delay = self.config.resolve_delay
                else:
                    self.resolve_delay -= 1

        self.full_columns = [column for column in self.full_columns if column.visible_characters]

    if (
        self.full_columns
        or self.active_columns
        or self.active_characters
        or self.pending_columns
        or not self.rain_complete
    ):
        self.update()
        return self.frame
    if not self.final_frame_shown:
        self.final_frame_shown = True
        self.update()
        return self.frame
    raise StopIteration

build()

Build the initial state of the effect.

Source code in terminaltexteffects/effects/effect_matrix.py
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
def build(self) -> None:
    """Build the initial state of the effect."""
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters():
        resolve_scn = character.animation.new_scene(scene_id="resolve")
        for color in Gradient(self.config.highlight_color, final_gradient_mapping[character.input_coord], steps=8):
            resolve_scn.add_frame(
                character.input_symbol,
                self.config.final_gradient_frames,
                colors=ColorPair(fg=color),
            )

    for column_chars in self.terminal.get_characters_grouped(
        self.terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
        outer_fill_chars=True,
        inner_fill_chars=True,
    ):
        column_chars.reverse()
        self.pending_columns.append(
            MatrixIterator.RainColumn(column_chars, self.terminal, self.config, self.rain_colors),
        )
    random.shuffle(self.pending_columns)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_matrix.py
77
78
79
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return Matrix, MatrixConfig
