MiddleOut

Demo

Quick Start

middleout.py
from terminaltexteffects.effects.effect_middleout import MiddleOut

effect = MiddleOut("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Text expands in a single row or column in the middle of the canvas then out.

Classes:

Name Description
MiddleOut

Text expands in a single row or column in the middle of the canvas then out.
MiddleOutConfig

Configuration for the Middleout effect.
MiddleOutIterator

Iterates over the effect's frames. Does not normally need to be called directly.

MiddleOut

Bases: BaseEffect[MiddleOutConfig]

Text expands in a single row or column in the middle of the canvas then out.

Attributes:

Name Type Description
effect_config MiddleOutConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_middleout.py
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
class MiddleOut(BaseEffect[MiddleOutConfig]):
    """Text expands in a single row or column in the middle of the canvas then out.

    Attributes:
        effect_config (MiddleOutConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[MiddleOutConfig]:
        return MiddleOutConfig

    @property
    def _iterator_cls(self) -> type[MiddleOutIterator]:
        return MiddleOutIterator

MiddleOutConfig dataclass

Bases: ArgsDataClass

Configuration for the Middleout effect.

Attributes:

Name Type Description
starting_color Color

Color for the initial text in the center of the canvas.
expand_direction Literal['vertical', 'horizontal']

Direction the text will expand. Choices: " "vertical, horizontal.
center_movement_speed float

Speed of the characters during the initial expansion of the center " "vertical/horiztonal. Valid values are n > 0.
full_movement_speed float

Speed of the characters during the final full expansion. Valid values are n > 0.
center_easing EasingFunction

Easing function to use for initial expansion.
full_easing EasingFunction

Easing function to use for full expansion.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color " "is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps " "will create a smoother and longer gradient animation. Valid values are n > 0.
final_gradient_direction Direction

Direction of the final gradient.
Source code in terminaltexteffects/effects/effect_middleout.py
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
@argclass(
    name="middleout",
    help="Text expands in a single row or column in the middle of the canvas then out.",
    description="middleout | Text expands in a single row or column in the middle of the canvas then out.",
    epilog=(
        f"{argvalidators.EASING_EPILOG} Example: terminaltexteffects middleout --starting-color 8A008A "
        "--final-gradient-stops 8A008A 00D1FF FFFFFF --final-gradient-steps 12 --expand-direction vertical "
        "--center-movement-speed 0.35 --full-movement-speed 0.35 --center-easing IN_OUT_SINE "
        "--full-easing IN_OUT_SINE"
    ),
)
@dataclass
class MiddleOutConfig(ArgsDataClass):
    """Configuration for the Middleout effect.

    Attributes:
        starting_color (Color): Color for the initial text in the center of the canvas.
        expand_direction (typing.Literal["vertical", "horizontal"]): Direction the text will expand. Choices: "
            "vertical, horizontal.
        center_movement_speed (float): Speed of the characters during the initial expansion of the center "
            "vertical/horiztonal. Valid values are n > 0.
        full_movement_speed (float): Speed of the characters during the final full expansion. Valid values are n > 0.
        center_easing (easing.EasingFunction): Easing function to use for initial expansion.
        full_easing (easing.EasingFunction): Easing function to use for full expansion.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color "
            "is provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps "
            "will create a smoother and longer gradient animation. Valid values are n > 0.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.

    """

    starting_color: Color = ArgField(
        cmd_name="--starting-color",
        type_parser=argvalidators.ColorArg.type_parser,
        default=Color("ffffff"),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Color for the initial text in the center of the canvas.",
    )  # type: ignore[assignment]
    """Color : Color for the initial text in the center of the canvas."""

    expand_direction: typing.Literal["vertical", "horizontal"] = ArgField(
        cmd_name="--expand-direction",
        default="vertical",
        choices=["vertical", "horizontal"],
        help="Direction the text will expand.",
    )  # type: ignore[assignment]
    """str : Direction the text will expand."""

    center_movement_speed: float = ArgField(
        cmd_name="--center-movement-speed",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.35,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Speed of the characters during the initial expansion of the center vertical/horiztonal line. ",
    )  # type: ignore[assignment]
    """float : Speed of the characters during the initial expansion of the center vertical/horiztonal line. """

    full_movement_speed: float = ArgField(
        cmd_name="--full-movement-speed",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.35,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Speed of the characters during the final full expansion. ",
    )  # type: ignore[assignment]
    """float : Speed of the characters during the final full expansion. """

    center_easing: easing.EasingFunction = ArgField(
        cmd_name="--center-easing",
        default=easing.in_out_sine,
        type_parser=argvalidators.Ease.type_parser,
        help="Easing function to use for initial expansion.",
    )  # type: ignore[assignment]
    """easing.EasingFunction : Easing function to use for initial expansion."""

    full_easing: easing.EasingFunction = ArgField(
        cmd_name="--full-easing",
        default=easing.in_out_sine,
        type_parser=argvalidators.Ease.type_parser,
        help="Easing function to use for full expansion.",
    )  # type: ignore[assignment]
    """easing.EasingFunction : Easing function to use for full expansion."""

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name="--final-gradient-stops",
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("8A008A"), Color("00D1FF"), Color("FFFFFF")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). "
        "If only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--final-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a "
        "smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will "
        "create a smoother and longer gradient animation."
    )

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.VERTICAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    """Gradient.Direction : Direction of the final gradient."""

    @classmethod
    def get_effect_class(cls) -> type[MiddleOut]:
        """Get the effect class associated with this configuration."""
        return MiddleOut

center_easing = ArgField(cmd_name='--center-easing', default=easing.in_out_sine, type_parser=argvalidators.Ease.type_parser, help='Easing function to use for initial expansion.') class-attribute instance-attribute

easing.EasingFunction : Easing function to use for initial expansion.

center_movement_speed = ArgField(cmd_name='--center-movement-speed', type_parser=argvalidators.PositiveFloat.type_parser, default=0.35, metavar=argvalidators.PositiveFloat.METAVAR, help='Speed of the characters during the initial expansion of the center vertical/horiztonal line. ') class-attribute instance-attribute

float : Speed of the characters during the initial expansion of the center vertical/horiztonal line.

expand_direction = ArgField(cmd_name='--expand-direction', default='vertical', choices=['vertical', 'horizontal'], help='Direction the text will expand.') class-attribute instance-attribute

str : Direction the text will expand.

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.VERTICAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_steps = ArgField(cmd_name='--final-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

final_gradient_stops = ArgField(cmd_name='--final-gradient-stops', type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('8A008A'), Color('00D1FF'), Color('FFFFFF')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

full_easing = ArgField(cmd_name='--full-easing', default=easing.in_out_sine, type_parser=argvalidators.Ease.type_parser, help='Easing function to use for full expansion.') class-attribute instance-attribute

easing.EasingFunction : Easing function to use for full expansion.

full_movement_speed = ArgField(cmd_name='--full-movement-speed', type_parser=argvalidators.PositiveFloat.type_parser, default=0.35, metavar=argvalidators.PositiveFloat.METAVAR, help='Speed of the characters during the final full expansion. ') class-attribute instance-attribute

float : Speed of the characters during the final full expansion.

starting_color = ArgField(cmd_name='--starting-color', type_parser=argvalidators.ColorArg.type_parser, default=Color('ffffff'), metavar=argvalidators.ColorArg.METAVAR, help='Color for the initial text in the center of the canvas.') class-attribute instance-attribute

Color : Color for the initial text in the center of the canvas.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_middleout.py
146
147
148
149
@classmethod
def get_effect_class(cls) -> type[MiddleOut]:
    """Get the effect class associated with this configuration."""
    return MiddleOut

MiddleOutIterator

Bases: BaseEffectIterator[MiddleOutConfig]

Iterates over the frames of the MiddleOut effect.

Source code in terminaltexteffects/effects/effect_middleout.py
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
class MiddleOutIterator(BaseEffectIterator[MiddleOutConfig]):
    """Iterates over the frames of the MiddleOut effect."""

    def __init__(self, effect: MiddleOut) -> None:
        """Initialize the MiddleOut effect iterator.

        Args:
            effect (MiddleOut): The MiddleOut effect to iterate over.

        """
        super().__init__(effect)
        self.pending_chars: list[EffectCharacter] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.phase = "center"
        self.build()

    def build(self) -> None:
        """Build the initial state of the effect."""
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters():
            self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
            character.motion.set_coordinate(self.terminal.canvas.center)
            # setup waypoints
            if self.config.expand_direction == "vertical":
                column = character.input_coord.column
                row = self.terminal.canvas.center_row
            else:
                column = self.terminal.canvas.center_column
                row = character.input_coord.row
            center_path = character.motion.new_path(
                speed=self.config.center_movement_speed,
                ease=self.config.center_easing,
            )
            center_path.new_waypoint(Coord(column, row))
            full_path = character.motion.new_path(
                path_id="full",
                speed=self.config.full_movement_speed,
                ease=self.config.full_easing,
            )
            full_path.new_waypoint(character.input_coord, waypoint_id="full")

            # setup scenes
            full_scene = character.animation.new_scene(scene_id="full")
            full_gradient = Gradient(self.config.starting_color, self.character_final_color_map[character], steps=10)
            full_scene.apply_gradient_to_symbols(character.input_symbol, 10, fg_gradient=full_gradient)

            # initialize character state
            character.motion.activate_path(center_path)
            character.animation.set_appearance(character.input_symbol, ColorPair(fg=self.config.starting_color))
            self.terminal.set_character_visibility(character, is_visible=True)
            self.active_characters.add(character)

    def __next__(self) -> str:
        """Return the next frame in the animation."""
        if self.phase == "center" and not self.active_characters:
            self.phase = "full"
            self.active_characters = set(self.terminal.get_characters())
            for character in self.active_characters:
                character.motion.activate_path(character.motion.query_path("full"))
                character.animation.activate_scene(character.animation.query_scene("full"))
        if self.active_characters:
            self.update()
            return self.frame
        raise StopIteration

__init__(effect)

Initialize the MiddleOut effect iterator.

Parameters:

Name Type Description Default
effect MiddleOut

The MiddleOut effect to iterate over.

 required
Source code in terminaltexteffects/effects/effect_middleout.py
155
156
157
158
159
160
161
162
163
164
165
166
def __init__(self, effect: MiddleOut) -> None:
    """Initialize the MiddleOut effect iterator.

    Args:
        effect (MiddleOut): The MiddleOut effect to iterate over.

    """
    super().__init__(effect)
    self.pending_chars: list[EffectCharacter] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.phase = "center"
    self.build()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_middleout.py
211
212
213
214
215
216
217
218
219
220
221
222
def __next__(self) -> str:
    """Return the next frame in the animation."""
    if self.phase == "center" and not self.active_characters:
        self.phase = "full"
        self.active_characters = set(self.terminal.get_characters())
        for character in self.active_characters:
            character.motion.activate_path(character.motion.query_path("full"))
            character.animation.activate_scene(character.animation.query_scene("full"))
    if self.active_characters:
        self.update()
        return self.frame
    raise StopIteration

build()

Build the initial state of the effect.

Source code in terminaltexteffects/effects/effect_middleout.py
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
def build(self) -> None:
    """Build the initial state of the effect."""
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters():
        self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
        character.motion.set_coordinate(self.terminal.canvas.center)
        # setup waypoints
        if self.config.expand_direction == "vertical":
            column = character.input_coord.column
            row = self.terminal.canvas.center_row
        else:
            column = self.terminal.canvas.center_column
            row = character.input_coord.row
        center_path = character.motion.new_path(
            speed=self.config.center_movement_speed,
            ease=self.config.center_easing,
        )
        center_path.new_waypoint(Coord(column, row))
        full_path = character.motion.new_path(
            path_id="full",
            speed=self.config.full_movement_speed,
            ease=self.config.full_easing,
        )
        full_path.new_waypoint(character.input_coord, waypoint_id="full")

        # setup scenes
        full_scene = character.animation.new_scene(scene_id="full")
        full_gradient = Gradient(self.config.starting_color, self.character_final_color_map[character], steps=10)
        full_scene.apply_gradient_to_symbols(character.input_symbol, 10, fg_gradient=full_gradient)

        # initialize character state
        character.motion.activate_path(center_path)
        character.animation.set_appearance(character.input_symbol, ColorPair(fg=self.config.starting_color))
        self.terminal.set_character_visibility(character, is_visible=True)
        self.active_characters.add(character)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_middleout.py
21
22
23
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return MiddleOut, MiddleOutConfig
