Pour

Demo

Quick Start

pour.py
from terminaltexteffects.effects.effect_pour import Pour

effect = Pour("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Pours the characters back and forth from the top, bottom, left, or right.

Classes:

Name Description
Pour

Pours the characters back and forth from the top, bottom, left, or right.
PourConfig

Configuration for the Pour effect.
PourIterator

Iterates over the frames of the Pour effect. Does not normally need to be called directly.

Pour

Bases: BaseEffect[PourConfig]

Pours the characters back and forth from the top, bottom, left, or right.

Attributes:

Name Type Description
effect_config PourConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_pour.py
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
class Pour(BaseEffect[PourConfig]):
    """Pours the characters back and forth from the top, bottom, left, or right.

    Attributes:
        effect_config (PourConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[PourConfig]:
        return PourConfig

    @property
    def _iterator_cls(self) -> type[PourIterator]:
        return PourIterator

PourConfig dataclass

Bases: ArgsDataClass

Configuration for the Pour effect.

Attributes:

Name Type Description
pour_direction str

Direction the text will pour. Valid values are "up", "down", "left", and "right".
pour_speed int

Number of characters poured in per tick. Increase to speed up the effect. " "Valid values are n > 0.
movement_speed float

Movement speed of the characters. Valid values are n > 0.
gap int

Number of frames to wait between each character in the pour effect. Increase to slow down effect " "and create a more defined back and forth motion. Valid values are n >= 0.
starting_color Color

Color of the characters before the gradient starts.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the character gradient. If only one color " "is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Number of gradient steps to use. More steps will create a " "smoother and longer gradient animation.
final_gradient_frames int

Number of frames to display each gradient step. Increase to slow down the " "gradient animation.
final_gradient_direction Direction

Direction of the final gradient.
easing EasingFunction

Easing function to use for character movement.
Source code in terminaltexteffects/effects/effect_pour.py
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
@argclass(
    name="pour",
    help="Pours the characters into position from the given direction.",
    description="pour | Pours the characters into position from the given direction.",
    epilog=(
        f"{argvalidators.EASING_EPILOG} Example: terminaltexteffects pour --pour-direction down "
        "--movement-speed 0.2 --gap 1 --starting-color FFFFFF --final-gradient-stops 8A008A 00D1FF FFFFFF "
        "--easing IN_QUAD"
    ),
)
@dataclass
class PourConfig(ArgsDataClass):
    """Configuration for the Pour effect.

    Attributes:
        pour_direction (str): Direction the text will pour. Valid values are "up", "down", "left", and "right".
        pour_speed (int): Number of characters poured in per tick. Increase to speed up the effect. "
            "Valid values are n > 0.
        movement_speed (float): Movement speed of the characters. Valid values are n > 0.
        gap (int): Number of frames to wait between each character in the pour effect. Increase to slow down effect "
            "and create a more defined back and forth motion. Valid values are n >= 0.
        starting_color (Color): Color of the characters before the gradient starts.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the character gradient. If only one color "
            "is provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Number of gradient steps to use. More steps will create a "
            "smoother and longer gradient animation.
        final_gradient_frames (int): Number of frames to display each gradient step. Increase to slow down the "
            "gradient animation.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.
        easing (easing.EasingFunction): Easing function to use for character movement.

    """

    pour_direction: typing.Literal["up", "down", "left", "right"] = ArgField(
        cmd_name=["--pour-direction"],
        default="down",
        choices=["up", "down", "left", "right"],
        help="Direction the text will pour.",
    )  # type: ignore[assignment]
    "typing.Literal['up', 'down', 'left', 'right'] : Direction the text will pour."

    pour_speed: int = ArgField(
        cmd_name="--pour-speed",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=1,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of characters poured in per tick. Increase to speed up the effect.",
    )  # type: ignore[assignment]
    "int : Number of characters poured in per tick. Increase to speed up the effect."

    movement_speed: float = ArgField(
        cmd_name="--movement-speed",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.2,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Movement speed of the characters. ",
    )  # type: ignore[assignment]
    "float : Movement speed of the characters."

    gap: int = ArgField(
        cmd_name="--gap",
        type_parser=argvalidators.NonNegativeInt.type_parser,
        default=1,
        metavar=argvalidators.NonNegativeInt.METAVAR,
        help="Number of frames to wait between each character in the pour effect. Increase to slow down effect "
        "and create a more defined back and forth motion.",
    )  # type: ignore[assignment]
    "int : Number of frames to wait between each character in the pour effect."

    starting_color: Color = ArgField(
        cmd_name=["--starting-color"],
        type_parser=argvalidators.ColorArg.type_parser,
        default=Color("ffffff"),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Color of the characters before the gradient starts.",
    )  # type: ignore[assignment]
    "Color : Color of the characters before the gradient starts."

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--final-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("8A008A"), Color("00D1FF"), Color("FFFFFF")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient. If only one color is provided, "
        "the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    "tuple[Color, ...] : Tuple of colors for the character gradient."

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name=["--final-gradient-steps"],
        type_parser=argvalidators.PositiveInt.type_parser,
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of gradient steps to use. More steps will create a smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use."

    final_gradient_frames: int = ArgField(
        cmd_name=["--final-gradient-frames"],
        type_parser=argvalidators.PositiveInt.type_parser,
        default=10,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Number of frames to display each gradient step. Increase to slow down the gradient animation.",
    )  # type: ignore[assignment]
    "int : Number of frames to display each gradient step. Increase to slow down the gradient animation."

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.VERTICAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the final gradient."

    movement_easing: easing.EasingFunction = ArgField(
        cmd_name="--movement-easing",
        default=easing.in_quad,
        type_parser=argvalidators.Ease.type_parser,
        help="Easing function to use for character movement.",
    )  # type: ignore[assignment]
    "easing.EasingFunction : Easing function to use for character movement."

    @classmethod
    def get_effect_class(cls) -> type[Pour]:
        """Get the effect class associated with this configuration."""
        return Pour

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.VERTICAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_frames = ArgField(cmd_name=['--final-gradient-frames'], type_parser=argvalidators.PositiveInt.type_parser, default=10, metavar=argvalidators.PositiveInt.METAVAR, help='Number of frames to display each gradient step. Increase to slow down the gradient animation.') class-attribute instance-attribute

int : Number of frames to display each gradient step. Increase to slow down the gradient animation.

final_gradient_steps = ArgField(cmd_name=['--final-gradient-steps'], type_parser=argvalidators.PositiveInt.type_parser, default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use.

final_gradient_stops = ArgField(cmd_name=['--final-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('8A008A'), Color('00D1FF'), Color('FFFFFF')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient. If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the character gradient.

gap = ArgField(cmd_name='--gap', type_parser=argvalidators.NonNegativeInt.type_parser, default=1, metavar=argvalidators.NonNegativeInt.METAVAR, help='Number of frames to wait between each character in the pour effect. Increase to slow down effect and create a more defined back and forth motion.') class-attribute instance-attribute

int : Number of frames to wait between each character in the pour effect.

movement_easing = ArgField(cmd_name='--movement-easing', default=easing.in_quad, type_parser=argvalidators.Ease.type_parser, help='Easing function to use for character movement.') class-attribute instance-attribute

easing.EasingFunction : Easing function to use for character movement.

movement_speed = ArgField(cmd_name='--movement-speed', type_parser=argvalidators.PositiveFloat.type_parser, default=0.2, metavar=argvalidators.PositiveFloat.METAVAR, help='Movement speed of the characters. ') class-attribute instance-attribute

float : Movement speed of the characters.

pour_direction = ArgField(cmd_name=['--pour-direction'], default='down', choices=['up', 'down', 'left', 'right'], help='Direction the text will pour.') class-attribute instance-attribute

typing.Literal['up', 'down', 'left', 'right'] : Direction the text will pour.

pour_speed = ArgField(cmd_name='--pour-speed', type_parser=argvalidators.PositiveInt.type_parser, default=1, metavar=argvalidators.PositiveInt.METAVAR, help='Number of characters poured in per tick. Increase to speed up the effect.') class-attribute instance-attribute

int : Number of characters poured in per tick. Increase to speed up the effect.

starting_color = ArgField(cmd_name=['--starting-color'], type_parser=argvalidators.ColorArg.type_parser, default=Color('ffffff'), metavar=argvalidators.ColorArg.METAVAR, help='Color of the characters before the gradient starts.') class-attribute instance-attribute

Color : Color of the characters before the gradient starts.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_pour.py
150
151
152
153
@classmethod
def get_effect_class(cls) -> type[Pour]:
    """Get the effect class associated with this configuration."""
    return Pour

PourIterator

Bases: BaseEffectIterator[PourConfig]

Iterator for the Pour effect.

Source code in terminaltexteffects/effects/effect_pour.py
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
class PourIterator(BaseEffectIterator[PourConfig]):
    """Iterator for the Pour effect."""

    class PourDirection(Enum):
        """Pour direction enumeration."""

        UP = auto()
        DOWN = auto()
        LEFT = auto()
        RIGHT = auto()

    def __init__(self, effect: Pour) -> None:
        """Initialize the iterator with the provided effect.

        Args:
            effect (Pour): The effect to use for the iterator.

        """
        super().__init__(effect)
        self.pending_groups: list[list[EffectCharacter]] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.build()

    def build(self) -> None:
        """Build the initial state of the effect."""
        self._pour_direction = {
            "down": PourIterator.PourDirection.DOWN,
            "up": PourIterator.PourDirection.UP,
            "left": PourIterator.PourDirection.LEFT,
            "right": PourIterator.PourDirection.RIGHT,
        }.get(self.config.pour_direction, PourIterator.PourDirection.DOWN)
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters():
            self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
        sort_map = {
            PourIterator.PourDirection.DOWN: Terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
            PourIterator.PourDirection.UP: Terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
            PourIterator.PourDirection.LEFT: Terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
            PourIterator.PourDirection.RIGHT: Terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
        }
        groups = self.terminal.get_characters_grouped(grouping=sort_map[self._pour_direction])
        for i, group in enumerate(groups):
            for character in group:
                self.terminal.set_character_visibility(character, is_visible=False)
                if self._pour_direction == PourIterator.PourDirection.DOWN:
                    character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.top))
                elif self._pour_direction == PourIterator.PourDirection.UP:
                    character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.bottom))
                elif self._pour_direction == PourIterator.PourDirection.LEFT:
                    character.motion.set_coordinate(Coord(self.terminal.canvas.right, character.input_coord.row))
                elif self._pour_direction == PourIterator.PourDirection.RIGHT:
                    character.motion.set_coordinate(Coord(self.terminal.canvas.left, character.input_coord.row))
                input_coord_path = character.motion.new_path(
                    speed=self.config.movement_speed,
                    ease=self.config.movement_easing,
                )
                input_coord_path.new_waypoint(character.input_coord)
                character.motion.activate_path(input_coord_path)

                pour_gradient = Gradient(
                    self.config.starting_color,
                    self.character_final_color_map[character],
                    steps=self.config.final_gradient_steps,
                )
                pour_scn = character.animation.new_scene()
                pour_scn.apply_gradient_to_symbols(
                    character.input_symbol,
                    self.config.final_gradient_frames,
                    fg_gradient=pour_gradient,
                )
                character.animation.activate_scene(pour_scn)
            if i % 2 == 0:
                self.pending_groups.append(group)
            else:
                self.pending_groups.append(group[::-1])
        self.gap = 0
        self.current_group = self.pending_groups.pop(0)

    def __next__(self) -> str:
        """Return the next frame in the animation."""
        if self.pending_groups or self.active_characters or self.current_group:
            if not self.current_group and self.pending_groups:
                self.current_group = self.pending_groups.pop(0)
            if self.current_group:
                if not self.gap:
                    for _ in range(self.config.pour_speed):
                        if self.current_group:
                            next_character = self.current_group.pop(0)
                            self.terminal.set_character_visibility(next_character, is_visible=True)
                            self.active_characters.add(next_character)
                    self.gap = self.config.gap
                else:
                    self.gap -= 1
            self.update()
            return self.frame
        raise StopIteration

PourDirection

Bases: Enum

Pour direction enumeration.

Source code in terminaltexteffects/effects/effect_pour.py
159
160
161
162
163
164
165
class PourDirection(Enum):
    """Pour direction enumeration."""

    UP = auto()
    DOWN = auto()
    LEFT = auto()
    RIGHT = auto()

__init__(effect)

Initialize the iterator with the provided effect.

Parameters:

Name Type Description Default
effect Pour

The effect to use for the iterator.

 required
Source code in terminaltexteffects/effects/effect_pour.py
167
168
169
170
171
172
173
174
175
176
177
def __init__(self, effect: Pour) -> None:
    """Initialize the iterator with the provided effect.

    Args:
        effect (Pour): The effect to use for the iterator.

    """
    super().__init__(effect)
    self.pending_groups: list[list[EffectCharacter]] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.build()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_pour.py
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
def __next__(self) -> str:
    """Return the next frame in the animation."""
    if self.pending_groups or self.active_characters or self.current_group:
        if not self.current_group and self.pending_groups:
            self.current_group = self.pending_groups.pop(0)
        if self.current_group:
            if not self.gap:
                for _ in range(self.config.pour_speed):
                    if self.current_group:
                        next_character = self.current_group.pop(0)
                        self.terminal.set_character_visibility(next_character, is_visible=True)
                        self.active_characters.add(next_character)
                self.gap = self.config.gap
            else:
                self.gap -= 1
        self.update()
        return self.frame
    raise StopIteration

build()

Build the initial state of the effect.

Source code in terminaltexteffects/effects/effect_pour.py
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
def build(self) -> None:
    """Build the initial state of the effect."""
    self._pour_direction = {
        "down": PourIterator.PourDirection.DOWN,
        "up": PourIterator.PourDirection.UP,
        "left": PourIterator.PourDirection.LEFT,
        "right": PourIterator.PourDirection.RIGHT,
    }.get(self.config.pour_direction, PourIterator.PourDirection.DOWN)
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters():
        self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
    sort_map = {
        PourIterator.PourDirection.DOWN: Terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
        PourIterator.PourDirection.UP: Terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
        PourIterator.PourDirection.LEFT: Terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
        PourIterator.PourDirection.RIGHT: Terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
    }
    groups = self.terminal.get_characters_grouped(grouping=sort_map[self._pour_direction])
    for i, group in enumerate(groups):
        for character in group:
            self.terminal.set_character_visibility(character, is_visible=False)
            if self._pour_direction == PourIterator.PourDirection.DOWN:
                character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.top))
            elif self._pour_direction == PourIterator.PourDirection.UP:
                character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.bottom))
            elif self._pour_direction == PourIterator.PourDirection.LEFT:
                character.motion.set_coordinate(Coord(self.terminal.canvas.right, character.input_coord.row))
            elif self._pour_direction == PourIterator.PourDirection.RIGHT:
                character.motion.set_coordinate(Coord(self.terminal.canvas.left, character.input_coord.row))
            input_coord_path = character.motion.new_path(
                speed=self.config.movement_speed,
                ease=self.config.movement_easing,
            )
            input_coord_path.new_waypoint(character.input_coord)
            character.motion.activate_path(input_coord_path)

            pour_gradient = Gradient(
                self.config.starting_color,
                self.character_final_color_map[character],
                steps=self.config.final_gradient_steps,
            )
            pour_scn = character.animation.new_scene()
            pour_scn.apply_gradient_to_symbols(
                character.input_symbol,
                self.config.final_gradient_frames,
                fg_gradient=pour_gradient,
            )
            character.animation.activate_scene(pour_scn)
        if i % 2 == 0:
            self.pending_groups.append(group)
        else:
            self.pending_groups.append(group[::-1])
    self.gap = 0
    self.current_group = self.pending_groups.pop(0)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_pour.py
21
22
23
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return Pour, PourConfig
