Slice

Demo

Quick Start

slice.py
from terminaltexteffects.effects.effect_slice import Slice

effect = Slice("YourTextHere")
effect.effect_config.slice_direction = "diagonal"
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Slices the input in half and slides it into place from opposite directions.

Classes:

Name Description
Slice

Slices the input in half and slides it into place from opposite directions.
SliceConfig

Configuration for the Slice effect.
SliceIterator

Effect iterator for the effect. Does not normally need to be called directly.

Slice

Bases: BaseEffect[SliceConfig]

Slices the input in half and slides it into place from opposite directions.

Attributes:

Name Type Description
effect_config SliceConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_slice.py
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
class Slice(BaseEffect[SliceConfig]):
    """Slices the input in half and slides it into place from opposite directions.

    Attributes:
        effect_config (SliceConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[SliceConfig]:
        return SliceConfig

    @property
    def _iterator_cls(self) -> type[SliceIterator]:
        return SliceIterator

SliceConfig dataclass

Bases: ArgsDataClass

Configuration for the Slice effect.

Attributes:

Name Type Description
slice_direction Literal['vertical', 'horizontal', 'diagonal']

Direction of the slice.
movement_speed float

Movement speed of the characters. Valid values are n > 0.
movement_easing EasingFunction

Easing function to use for character movement.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
final_gradient_direction Direction

Direction of the final gradient.
Source code in terminaltexteffects/effects/effect_slice.py
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
@argclass(
    name="slice",
    help="Slices the input in half and slides it into place from opposite directions.",
    description="slice | Slices the input in half and slides it into place from opposite directions.",
    epilog=(
        f"{argvalidators.EASING_EPILOG} Example: terminaltexteffects slice --final-gradient-stops 8A008A 00D1FF "
        "FFFFFF --final-gradient-steps 12 --slice-direction vertical--movement-speed 0.15 "
        "--movement-easing IN_OUT_EXPO"
    ),
)
@dataclass
class SliceConfig(ArgsDataClass):
    """Configuration for the Slice effect.

    Attributes:
        slice_direction (typing.Literal["vertical", "horizontal", "diagonal"]): Direction of the slice.
        movement_speed (float): Movement speed of the characters. Valid values are n > 0.
        movement_easing (easing.EasingFunction): Easing function to use for character movement.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color is
            provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps will
            create a smoother and longer gradient animation. Valid values are n > 0.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.

    """

    slice_direction: typing.Literal["vertical", "horizontal", "diagonal"] = ArgField(
        cmd_name="--slice-direction",
        default="vertical",
        choices=["vertical", "horizontal", "diagonal"],
        help="Direction of the slice.",
    )  # type: ignore[assignment]
    "typing.Literal['vertical', 'horizontal', 'diagonal'] : Direction of the slice."

    movement_speed: float = ArgField(
        cmd_name="--movement-speed",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.15,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Movement speed of the characters. ",
    )  # type: ignore[assignment]
    "float : Movement speed of the characters. Doubled for horizontal slices."

    movement_easing: easing.EasingFunction = ArgField(
        cmd_name="--movement-easing",
        type_parser=argvalidators.Ease.type_parser,
        default=easing.in_out_expo,
        help="Easing function to use for character movement.",
    )  # type: ignore[assignment]
    "easing.EasingFunction : Easing function to use for character movement."

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--final-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("8A008A"), Color("00D1FF"), Color("FFFFFF")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If "
        "only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--final-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a "
        "smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will "
        "create a smoother and longer gradient animation."
    )

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.DIAGONAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the final gradient."

    @classmethod
    def get_effect_class(cls) -> type[Slice]:
        """Get the effect class associated with this configuration."""
        return Slice

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.DIAGONAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_steps = ArgField(cmd_name='--final-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

final_gradient_stops = ArgField(cmd_name=['--final-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('8A008A'), Color('00D1FF'), Color('FFFFFF')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

movement_easing = ArgField(cmd_name='--movement-easing', type_parser=argvalidators.Ease.type_parser, default=easing.in_out_expo, help='Easing function to use for character movement.') class-attribute instance-attribute

easing.EasingFunction : Easing function to use for character movement.

movement_speed = ArgField(cmd_name='--movement-speed', type_parser=argvalidators.PositiveFloat.type_parser, default=0.15, metavar=argvalidators.PositiveFloat.METAVAR, help='Movement speed of the characters. ') class-attribute instance-attribute

float : Movement speed of the characters. Doubled for horizontal slices.

slice_direction = ArgField(cmd_name='--slice-direction', default='vertical', choices=['vertical', 'horizontal', 'diagonal'], help='Direction of the slice.') class-attribute instance-attribute

typing.Literal['vertical', 'horizontal', 'diagonal'] : Direction of the slice.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_slice.py
113
114
115
116
@classmethod
def get_effect_class(cls) -> type[Slice]:
    """Get the effect class associated with this configuration."""
    return Slice

SliceIterator

Bases: BaseEffectIterator[SliceConfig]

Effect iterator for the Slice effect.

Source code in terminaltexteffects/effects/effect_slice.py
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
class SliceIterator(BaseEffectIterator[SliceConfig]):
    """Effect iterator for the Slice effect."""

    def __init__(self, effect: Slice) -> None:
        """Initialize the effect iterator."""
        super().__init__(effect)
        self.pending_groups: list[list[EffectCharacter]] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.build()

    def build(self) -> None:  # noqa: PLR0915
        """Build the effect."""
        slice_direction_map = {
            "vertical": self.terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
            "horizontal": self.terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
            "diagonal": self.terminal.CharacterGroup.DIAGONAL_BOTTOM_LEFT_TO_TOP_RIGHT,
        }
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters():
            self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
            character.animation.set_appearance(
                character.input_symbol,
                ColorPair(fg=self.character_final_color_map[character]),
            )
        if self.config.slice_direction == "vertical":
            self.rows = self.terminal.get_characters_grouped(grouping=slice_direction_map[self.config.slice_direction])
            for row_index, row in enumerate(self.rows):
                new_row = []

                left_half = [
                    character
                    for character in row
                    if character.input_coord.column <= self.terminal.canvas.text_center_column
                ]
                for character in left_half:
                    character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.top + 1))
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                opposite_row = self.rows[-(row_index + 1)]
                right_half = [c for c in opposite_row if c.input_coord.column > self.terminal.canvas.text_center_column]
                for character in right_half:
                    character.motion.set_coordinate(
                        Coord(character.input_coord.column, self.terminal.canvas.bottom - 1),
                    )
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                new_row.extend(left_half)
                new_row.extend(right_half)
                self.active_characters = self.active_characters.union(new_row)
        elif self.config.slice_direction == "horizontal":
            self.config.movement_speed *= 2
            self.columns = self.terminal.get_characters_grouped(
                grouping=slice_direction_map[self.config.slice_direction],
                outer_fill_chars=True,
                inner_fill_chars=True,
            )
            trimmed_columns = []
            for column in self.columns:
                new_column = [
                    character
                    for character in column
                    if (
                        self.terminal.canvas.text_left
                        <= character.input_coord.column
                        <= self.terminal.canvas.text_right
                    )
                    and (self.terminal.canvas.text_bottom <= character.input_coord.row <= self.terminal.canvas.text_top)
                ]
                if new_column:
                    trimmed_columns.append(new_column)
            self.columns = trimmed_columns
            mid_point = self.terminal.canvas.text_center_row
            for column_index, column in enumerate(self.columns):
                new_column = []
                bottom_half = [character for character in column if character.input_coord.row <= mid_point]
                for character in bottom_half:
                    character.motion.set_coordinate(Coord(self.terminal.canvas.left - 1, character.input_coord.row))
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                opposite_column = self.columns[-(column_index + 1)]
                top_half = [c for c in opposite_column if c.input_coord.row > mid_point]
                for character in top_half:
                    character.motion.set_coordinate(Coord(self.terminal.canvas.right + 1, character.input_coord.row))
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                new_column.extend(bottom_half)
                new_column.extend(top_half)
                self.active_characters = self.active_characters.union(new_column)
        elif self.config.slice_direction == "diagonal":
            self.diagonals = self.terminal.get_characters_grouped(
                grouping=slice_direction_map[self.config.slice_direction],
            )
            left = self.diagonals[: len(self.diagonals) // 2]
            right = self.diagonals[len(self.diagonals) // 2 :]
            while left or right:
                new_group = []
                if left:
                    left_group = left.pop(0)
                    origin_coord = Coord(left_group[0].input_coord.column, self.terminal.canvas.bottom - 1)
                    for character in left_group:
                        character.motion.set_coordinate(origin_coord)
                        input_coord_path = character.motion.new_path(
                            speed=self.config.movement_speed,
                            ease=self.config.movement_easing,
                        )
                        input_coord_path.new_waypoint(character.input_coord)
                        character.motion.activate_path(input_coord_path)
                    new_group.extend(left_group)
                if right:
                    right_group = right.pop(0)
                    origin_coord = Coord(right_group[-1].input_coord.column, self.terminal.canvas.top + 1)
                    for character in right_group:
                        character.motion.set_coordinate(origin_coord)
                        input_coord_path = character.motion.new_path(
                            speed=self.config.movement_speed,
                            ease=self.config.movement_easing,
                        )
                        input_coord_path.new_waypoint(character.input_coord)
                        character.motion.activate_path(input_coord_path)
                    new_group.extend(right_group)
                self.active_characters = self.active_characters.union(new_group)
        for character in self.active_characters:
            self.terminal.set_character_visibility(character, is_visible=True)

    def __next__(self) -> str:
        """Return the next frame in the animation."""
        if self.active_characters:
            self.update()
            return self.frame
        raise StopIteration

__init__(effect)

Initialize the effect iterator.

Source code in terminaltexteffects/effects/effect_slice.py
122
123
124
125
126
127
def __init__(self, effect: Slice) -> None:
    """Initialize the effect iterator."""
    super().__init__(effect)
    self.pending_groups: list[list[EffectCharacter]] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.build()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_slice.py
266
267
268
269
270
271
def __next__(self) -> str:
    """Return the next frame in the animation."""
    if self.active_characters:
        self.update()
        return self.frame
    raise StopIteration

build()

Build the effect.

Source code in terminaltexteffects/effects/effect_slice.py
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
def build(self) -> None:  # noqa: PLR0915
    """Build the effect."""
    slice_direction_map = {
        "vertical": self.terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
        "horizontal": self.terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
        "diagonal": self.terminal.CharacterGroup.DIAGONAL_BOTTOM_LEFT_TO_TOP_RIGHT,
    }
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters():
        self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
        character.animation.set_appearance(
            character.input_symbol,
            ColorPair(fg=self.character_final_color_map[character]),
        )
    if self.config.slice_direction == "vertical":
        self.rows = self.terminal.get_characters_grouped(grouping=slice_direction_map[self.config.slice_direction])
        for row_index, row in enumerate(self.rows):
            new_row = []

            left_half = [
                character
                for character in row
                if character.input_coord.column <= self.terminal.canvas.text_center_column
            ]
            for character in left_half:
                character.motion.set_coordinate(Coord(character.input_coord.column, self.terminal.canvas.top + 1))
                input_coord_path = character.motion.new_path(
                    speed=self.config.movement_speed,
                    ease=self.config.movement_easing,
                )
                input_coord_path.new_waypoint(character.input_coord)
                character.motion.activate_path(input_coord_path)
            opposite_row = self.rows[-(row_index + 1)]
            right_half = [c for c in opposite_row if c.input_coord.column > self.terminal.canvas.text_center_column]
            for character in right_half:
                character.motion.set_coordinate(
                    Coord(character.input_coord.column, self.terminal.canvas.bottom - 1),
                )
                input_coord_path = character.motion.new_path(
                    speed=self.config.movement_speed,
                    ease=self.config.movement_easing,
                )
                input_coord_path.new_waypoint(character.input_coord)
                character.motion.activate_path(input_coord_path)
            new_row.extend(left_half)
            new_row.extend(right_half)
            self.active_characters = self.active_characters.union(new_row)
    elif self.config.slice_direction == "horizontal":
        self.config.movement_speed *= 2
        self.columns = self.terminal.get_characters_grouped(
            grouping=slice_direction_map[self.config.slice_direction],
            outer_fill_chars=True,
            inner_fill_chars=True,
        )
        trimmed_columns = []
        for column in self.columns:
            new_column = [
                character
                for character in column
                if (
                    self.terminal.canvas.text_left
                    <= character.input_coord.column
                    <= self.terminal.canvas.text_right
                )
                and (self.terminal.canvas.text_bottom <= character.input_coord.row <= self.terminal.canvas.text_top)
            ]
            if new_column:
                trimmed_columns.append(new_column)
        self.columns = trimmed_columns
        mid_point = self.terminal.canvas.text_center_row
        for column_index, column in enumerate(self.columns):
            new_column = []
            bottom_half = [character for character in column if character.input_coord.row <= mid_point]
            for character in bottom_half:
                character.motion.set_coordinate(Coord(self.terminal.canvas.left - 1, character.input_coord.row))
                input_coord_path = character.motion.new_path(
                    speed=self.config.movement_speed,
                    ease=self.config.movement_easing,
                )
                input_coord_path.new_waypoint(character.input_coord)
                character.motion.activate_path(input_coord_path)
            opposite_column = self.columns[-(column_index + 1)]
            top_half = [c for c in opposite_column if c.input_coord.row > mid_point]
            for character in top_half:
                character.motion.set_coordinate(Coord(self.terminal.canvas.right + 1, character.input_coord.row))
                input_coord_path = character.motion.new_path(
                    speed=self.config.movement_speed,
                    ease=self.config.movement_easing,
                )
                input_coord_path.new_waypoint(character.input_coord)
                character.motion.activate_path(input_coord_path)
            new_column.extend(bottom_half)
            new_column.extend(top_half)
            self.active_characters = self.active_characters.union(new_column)
    elif self.config.slice_direction == "diagonal":
        self.diagonals = self.terminal.get_characters_grouped(
            grouping=slice_direction_map[self.config.slice_direction],
        )
        left = self.diagonals[: len(self.diagonals) // 2]
        right = self.diagonals[len(self.diagonals) // 2 :]
        while left or right:
            new_group = []
            if left:
                left_group = left.pop(0)
                origin_coord = Coord(left_group[0].input_coord.column, self.terminal.canvas.bottom - 1)
                for character in left_group:
                    character.motion.set_coordinate(origin_coord)
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                new_group.extend(left_group)
            if right:
                right_group = right.pop(0)
                origin_coord = Coord(right_group[-1].input_coord.column, self.terminal.canvas.top + 1)
                for character in right_group:
                    character.motion.set_coordinate(origin_coord)
                    input_coord_path = character.motion.new_path(
                        speed=self.config.movement_speed,
                        ease=self.config.movement_easing,
                    )
                    input_coord_path.new_waypoint(character.input_coord)
                    character.motion.activate_path(input_coord_path)
                new_group.extend(right_group)
            self.active_characters = self.active_characters.union(new_group)
    for character in self.active_characters:
        self.terminal.set_character_visibility(character, is_visible=True)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_slice.py
20
21
22
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return Slice, SliceConfig
