Swarm

Demo

Quick Start

swarm.py
from terminaltexteffects.effects.effect_swarm import Swarm

effect = Swarm("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Characters are grouped into swarms and move around the terminal before settling into position.

Classes:

Name Description
Swarm

Characters are grouped into swarms and move around the terminal before settling into position.
SwarmConfig

Configuration for the Swarm effect.
SwarmIterator

Effect iterator for the Swarm effect. Does not normally need to be called directly.

Swarm

Bases: BaseEffect[SwarmConfig]

Characters are grouped into swarms and move around the terminal before settling into position.

Attributes:

Name Type Description
effect_config SwarmConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_swarm.py
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
class Swarm(BaseEffect[SwarmConfig]):
    """Characters are grouped into swarms and move around the terminal before settling into position.

    Attributes:
        effect_config (SwarmConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[SwarmConfig]:
        return SwarmConfig

    @property
    def _iterator_cls(self) -> type[SwarmIterator]:
        return SwarmIterator

SwarmConfig dataclass

Bases: ArgsDataClass

Configuration for the Swarm effect.

Attributes:

Name Type Description
base_color tuple[Color, ...]

Tuple of colors for the swarms.
flash_color Color

Color for the character flash. Characters flash when moving.
swarm_size float

Percent of total characters in each swarm. Valid values are 0 < n <= 1.
swarm_coordination float

Percent of characters in a swarm that move as a group. Valid values are 0 < n <= 1.
swarm_area_count_range tuple[int, int]

Range of the number of areas where characters will swarm. Valid values are n > 0.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
final_gradient_direction Direction

Direction of the final gradient.
Source code in terminaltexteffects/effects/effect_swarm.py
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
@argclass(
    name="swarm",
    help="Characters are grouped into swarms and move around the terminal before settling into position.",
    description="swarm | Characters are grouped into swarms and move around the terminal before settling "
    "into position.",
    epilog=(
        "Example: terminaltexteffects swarm --base-color 31a0d4 --flash-color f2ea79 --final-gradient-stops "
        "31b900 f0ff65 --final-gradient-steps 12 --swarm-size 0.1 --swarm-coordination 0.80 "
        "--swarm-area-count 2-4"
    ),
)
@dataclass
class SwarmConfig(ArgsDataClass):
    """Configuration for the Swarm effect.

    Attributes:
        base_color (tuple[Color, ...]): Tuple of colors for the swarms.
        flash_color (Color): Color for the character flash. Characters flash when moving.
        swarm_size (float): Percent of total characters in each swarm. Valid values are 0 < n <= 1.
        swarm_coordination (float): Percent of characters in a swarm that move as a group. Valid values are 0 < n <= 1.
        swarm_area_count_range (tuple[int, int]): Range of the number of areas where characters will swarm. Valid
            values are n > 0.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color is
            provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps will
            create a smoother and longer gradient animation. Valid values are n > 0.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.

    """

    base_color: tuple[Color, ...] = ArgField(
        cmd_name=["--base-color"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("31a0d4"),),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the swarms",
    )  # type: ignore[assignment]
    """tuple[Color, ...] : Tuple of colors for the swarms"""

    flash_color: Color = ArgField(
        cmd_name=["--flash-color"],
        type_parser=argvalidators.ColorArg.type_parser,
        default=Color("f2ea79"),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Color for the character flash. Characters flash when moving.",
    )  # type: ignore[assignment]
    """Color : Color for the character flash. Characters flash when moving."""

    swarm_size: float = ArgField(
        cmd_name="--swarm-size",
        type_parser=argvalidators.NonNegativeRatio.type_parser,
        metavar=argvalidators.NonNegativeRatio.METAVAR,
        default=0.1,
        help="Percent of total characters in each swarm.",
    )  # type: ignore[assignment]
    "float : Percent of total characters in each swarm."

    swarm_coordination: float = ArgField(
        cmd_name="--swarm-coordination",
        type_parser=argvalidators.NonNegativeRatio.type_parser,
        metavar=argvalidators.NonNegativeRatio.METAVAR,
        default=0.80,
        help="Percent of characters in a swarm that move as a group.",
    )  # type: ignore[assignment]
    "float : Percent of characters in a swarm that move as a group."

    swarm_area_count_range: tuple[int, int] = ArgField(
        cmd_name="--swarm-area-count-range",
        type_parser=argvalidators.PositiveIntRange.type_parser,
        metavar=argvalidators.PositiveIntRange.METAVAR,
        default=(2, 4),
        help="Range of the number of areas where characters will swarm.",
    )  # type: ignore[assignment]
    "tuple[int, int] : Range of the number of areas where characters will swarm."

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--final-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("31b900"), Color("f0ff65")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If "
        "only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name=["--final-gradient-steps"],
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a "
        "smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will "
        "create a smoother and longer gradient animation."
    )

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.HORIZONTAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the final gradient."

    @classmethod
    def get_effect_class(cls) -> type[Swarm]:
        """Get the effect class associated with this configuration."""
        return Swarm

base_color = ArgField(cmd_name=['--base-color'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('31a0d4'),), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the swarms') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the swarms

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.HORIZONTAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_steps = ArgField(cmd_name=['--final-gradient-steps'], type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

final_gradient_stops = ArgField(cmd_name=['--final-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('31b900'), Color('f0ff65')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

flash_color = ArgField(cmd_name=['--flash-color'], type_parser=argvalidators.ColorArg.type_parser, default=Color('f2ea79'), metavar=argvalidators.ColorArg.METAVAR, help='Color for the character flash. Characters flash when moving.') class-attribute instance-attribute

Color : Color for the character flash. Characters flash when moving.

swarm_area_count_range = ArgField(cmd_name='--swarm-area-count-range', type_parser=argvalidators.PositiveIntRange.type_parser, metavar=argvalidators.PositiveIntRange.METAVAR, default=(2, 4), help='Range of the number of areas where characters will swarm.') class-attribute instance-attribute

tuple[int, int] : Range of the number of areas where characters will swarm.

swarm_coordination = ArgField(cmd_name='--swarm-coordination', type_parser=argvalidators.NonNegativeRatio.type_parser, metavar=argvalidators.NonNegativeRatio.METAVAR, default=0.8, help='Percent of characters in a swarm that move as a group.') class-attribute instance-attribute

float : Percent of characters in a swarm that move as a group.

swarm_size = ArgField(cmd_name='--swarm-size', type_parser=argvalidators.NonNegativeRatio.type_parser, metavar=argvalidators.NonNegativeRatio.METAVAR, default=0.1, help='Percent of total characters in each swarm.') class-attribute instance-attribute

float : Percent of total characters in each swarm.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_swarm.py
149
150
151
152
@classmethod
def get_effect_class(cls) -> type[Swarm]:
    """Get the effect class associated with this configuration."""
    return Swarm

SwarmIterator

Bases: BaseEffectIterator[SwarmConfig]

Effect iterator for the Swarm effect.

Source code in terminaltexteffects/effects/effect_swarm.py
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
class SwarmIterator(BaseEffectIterator[SwarmConfig]):
    """Effect iterator for the Swarm effect."""

    def __init__(
        self,
        effect: Swarm,
    ) -> None:
        """Initialize the Swarm effect iterator.

        Args:
            effect (Swarm): The effect to use for the iterator.

        """
        super().__init__(effect)
        self.pending_chars: list[EffectCharacter] = []
        self.swarms: list[list[EffectCharacter]] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.build()

    def make_swarms(self, swarm_size: int) -> None:
        """Create swarms of characters.

        Args:
            swarm_size (int): The size of each swarm.

        """
        unswarmed_characters = self.terminal.get_characters(
            sort=self.terminal.CharacterSort.BOTTOM_TO_TOP_RIGHT_TO_LEFT,
        )

        while unswarmed_characters:
            new_swarm: list[EffectCharacter] = []
            for _ in range(swarm_size):
                if unswarmed_characters:
                    new_swarm.append(unswarmed_characters.pop())
                else:
                    break
            self.swarms.append(new_swarm)
        final_swarm = self.swarms.pop()
        if len(final_swarm) < swarm_size // 2:
            self.swarms[-1].extend(final_swarm)
        else:
            self.swarms.append(final_swarm)

    def build(self) -> None:  # noqa: PLR0915
        """Build the initial state of the effect."""
        swarm_size: int = max(round(len(self.terminal.get_characters()) * self.config.swarm_size), 1)
        self.make_swarms(swarm_size)
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        for character in self.terminal.get_characters():
            self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
        flash_list = [self.config.flash_color for _ in range(10)]
        for swarm in self.swarms:
            swarm_gradient = Gradient(random.choice(self.config.base_color), self.config.flash_color, steps=7)
            swarm_gradient_mirror = list(swarm_gradient) + flash_list + list(swarm_gradient)[::-1]
            swarm_area_coordinate_map: dict[Coord, list[Coord]] = {}
            swarm_spawn = self.terminal.canvas.random_coord(outside_scope=True)
            swarm_areas: list[Coord] = []
            swarm_area_count = random.randint(
                self.config.swarm_area_count_range[0],
                self.config.swarm_area_count_range[1],
            )
            # create areas where characters will swarm
            last_focus_coord = swarm_spawn
            radius = max(min(self.terminal.canvas.right, self.terminal.canvas.top) // 2, 1)
            while len(swarm_areas) < swarm_area_count:
                potential_focus_coords = geometry.find_coords_on_circle(last_focus_coord, radius)
                random.shuffle(potential_focus_coords)
                for coord in potential_focus_coords:
                    if self.terminal.canvas.coord_is_in_canvas(coord):
                        next_focus_coord = coord
                        break
                else:
                    next_focus_coord = self.terminal.canvas.random_coord()
                swarm_areas.append(next_focus_coord)
                swarm_area_coordinate_map[last_focus_coord] = geometry.find_coords_in_circle(
                    last_focus_coord,
                    max(min(self.terminal.canvas.right, self.terminal.canvas.top) // 6, 1) * 2,
                )
                last_focus_coord = next_focus_coord

            # assign characters waypoints for swarm areas and inner waypoints within the swarm areas
            for character in swarm:
                swarm_area_count = 0
                character.motion.set_coordinate(swarm_spawn)
                flash_scn = character.animation.new_scene(sync=Scene.SyncMetric.DISTANCE)
                for step in swarm_gradient_mirror:
                    flash_scn.add_frame(character.input_symbol, 1, colors=ColorPair(fg=step))
                for swarm_area_coords in swarm_area_coordinate_map.values():
                    swarm_area_name = f"{swarm_area_count}_swarm_area"
                    swarm_area_count += 1
                    origin_path = character.motion.new_path(path_id=swarm_area_name, speed=0.25, ease=easing.out_sine)
                    origin_path.new_waypoint(random.choice(swarm_area_coords), waypoint_id=swarm_area_name)
                    character.event_handler.register_event(
                        EventHandler.Event.PATH_ACTIVATED,
                        origin_path,
                        EventHandler.Action.ACTIVATE_SCENE,
                        flash_scn,
                    )
                    character.event_handler.register_event(
                        EventHandler.Event.PATH_ACTIVATED,
                        origin_path,
                        EventHandler.Action.SET_LAYER,
                        1,
                    )
                    character.event_handler.register_event(
                        EventHandler.Event.PATH_COMPLETE,
                        origin_path,
                        EventHandler.Action.DEACTIVATE_SCENE,
                        flash_scn,
                    )
                    inner_paths = 0
                    total_inner_paths = 2
                    while inner_paths < total_inner_paths:
                        next_coord = random.choice(swarm_area_coords)
                        inner_paths += 1
                        inner_path = character.motion.new_path(
                            path_id=str(len(character.motion.paths)),
                            speed=0.1,
                            ease=easing.in_out_sine,
                        )
                        inner_path.new_waypoint(next_coord, waypoint_id=str(len(character.motion.paths)))
                # create landing waypoint and scene
                input_path = character.motion.new_path(speed=0.3, ease=easing.in_out_quad)
                input_path.new_waypoint(character.input_coord)
                input_scn = character.animation.new_scene()
                for step in Gradient(self.config.flash_color, self.character_final_color_map[character], steps=10):
                    input_scn.add_frame(character.input_symbol, 3, colors=ColorPair(fg=step))
                character.event_handler.register_event(
                    EventHandler.Event.PATH_COMPLETE,
                    input_path,
                    EventHandler.Action.ACTIVATE_SCENE,
                    input_scn,
                )
                character.event_handler.register_event(
                    EventHandler.Event.PATH_COMPLETE,
                    input_path,
                    EventHandler.Action.SET_LAYER,
                    0,
                )
                character.event_handler.register_event(
                    EventHandler.Event.PATH_ACTIVATED,
                    input_path,
                    EventHandler.Action.ACTIVATE_SCENE,
                    flash_scn,
                )
                character.motion.chain_paths(list(character.motion.paths.values()))
        self.call_next = True
        self.active_swarm_area = "0_swarm_area"

    def __next__(self) -> str:
        """Return the next frame in the animation."""
        if self.swarms or self.active_characters:
            if self.swarms and self.call_next:
                self.call_next = False
                self.current_swarm = self.swarms.pop()
                self.active_swarm_area = "0_swarm_area"
                for character in self.current_swarm:
                    character.motion.activate_path(character.motion.query_path("0_swarm_area"))
                    self.terminal.set_character_visibility(character, is_visible=True)
                    self.active_characters.add(character)
            if len(self.active_characters) < len(self.current_swarm):  # some of the characters have landed
                self.call_next = True
            if self.current_swarm:
                for character in self.current_swarm:
                    if (
                        character.motion.active_path
                        and character.motion.active_path.path_id != self.active_swarm_area
                        and "swarm_area" in character.motion.active_path.path_id
                        and int(character.motion.active_path.path_id[0]) > int(self.active_swarm_area[0])
                    ):
                        self.active_swarm_area = character.motion.active_path.path_id
                        for other in self.current_swarm:
                            if other is not character and random.random() < self.config.swarm_coordination:
                                other.motion.activate_path(other.motion.paths[self.active_swarm_area])
                        break

            self.update()
            return self.frame
        raise StopIteration

__init__(effect)

Initialize the Swarm effect iterator.

Parameters:

Name Type Description Default
effect Swarm

The effect to use for the iterator.

 required
Source code in terminaltexteffects/effects/effect_swarm.py
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
def __init__(
    self,
    effect: Swarm,
) -> None:
    """Initialize the Swarm effect iterator.

    Args:
        effect (Swarm): The effect to use for the iterator.

    """
    super().__init__(effect)
    self.pending_chars: list[EffectCharacter] = []
    self.swarms: list[list[EffectCharacter]] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.build()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_swarm.py
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
def __next__(self) -> str:
    """Return the next frame in the animation."""
    if self.swarms or self.active_characters:
        if self.swarms and self.call_next:
            self.call_next = False
            self.current_swarm = self.swarms.pop()
            self.active_swarm_area = "0_swarm_area"
            for character in self.current_swarm:
                character.motion.activate_path(character.motion.query_path("0_swarm_area"))
                self.terminal.set_character_visibility(character, is_visible=True)
                self.active_characters.add(character)
        if len(self.active_characters) < len(self.current_swarm):  # some of the characters have landed
            self.call_next = True
        if self.current_swarm:
            for character in self.current_swarm:
                if (
                    character.motion.active_path
                    and character.motion.active_path.path_id != self.active_swarm_area
                    and "swarm_area" in character.motion.active_path.path_id
                    and int(character.motion.active_path.path_id[0]) > int(self.active_swarm_area[0])
                ):
                    self.active_swarm_area = character.motion.active_path.path_id
                    for other in self.current_swarm:
                        if other is not character and random.random() < self.config.swarm_coordination:
                            other.motion.activate_path(other.motion.paths[self.active_swarm_area])
                    break

        self.update()
        return self.frame
    raise StopIteration

build()

Build the initial state of the effect.

Source code in terminaltexteffects/effects/effect_swarm.py
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
def build(self) -> None:  # noqa: PLR0915
    """Build the initial state of the effect."""
    swarm_size: int = max(round(len(self.terminal.get_characters()) * self.config.swarm_size), 1)
    self.make_swarms(swarm_size)
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    for character in self.terminal.get_characters():
        self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
    flash_list = [self.config.flash_color for _ in range(10)]
    for swarm in self.swarms:
        swarm_gradient = Gradient(random.choice(self.config.base_color), self.config.flash_color, steps=7)
        swarm_gradient_mirror = list(swarm_gradient) + flash_list + list(swarm_gradient)[::-1]
        swarm_area_coordinate_map: dict[Coord, list[Coord]] = {}
        swarm_spawn = self.terminal.canvas.random_coord(outside_scope=True)
        swarm_areas: list[Coord] = []
        swarm_area_count = random.randint(
            self.config.swarm_area_count_range[0],
            self.config.swarm_area_count_range[1],
        )
        # create areas where characters will swarm
        last_focus_coord = swarm_spawn
        radius = max(min(self.terminal.canvas.right, self.terminal.canvas.top) // 2, 1)
        while len(swarm_areas) < swarm_area_count:
            potential_focus_coords = geometry.find_coords_on_circle(last_focus_coord, radius)
            random.shuffle(potential_focus_coords)
            for coord in potential_focus_coords:
                if self.terminal.canvas.coord_is_in_canvas(coord):
                    next_focus_coord = coord
                    break
            else:
                next_focus_coord = self.terminal.canvas.random_coord()
            swarm_areas.append(next_focus_coord)
            swarm_area_coordinate_map[last_focus_coord] = geometry.find_coords_in_circle(
                last_focus_coord,
                max(min(self.terminal.canvas.right, self.terminal.canvas.top) // 6, 1) * 2,
            )
            last_focus_coord = next_focus_coord

        # assign characters waypoints for swarm areas and inner waypoints within the swarm areas
        for character in swarm:
            swarm_area_count = 0
            character.motion.set_coordinate(swarm_spawn)
            flash_scn = character.animation.new_scene(sync=Scene.SyncMetric.DISTANCE)
            for step in swarm_gradient_mirror:
                flash_scn.add_frame(character.input_symbol, 1, colors=ColorPair(fg=step))
            for swarm_area_coords in swarm_area_coordinate_map.values():
                swarm_area_name = f"{swarm_area_count}_swarm_area"
                swarm_area_count += 1
                origin_path = character.motion.new_path(path_id=swarm_area_name, speed=0.25, ease=easing.out_sine)
                origin_path.new_waypoint(random.choice(swarm_area_coords), waypoint_id=swarm_area_name)
                character.event_handler.register_event(
                    EventHandler.Event.PATH_ACTIVATED,
                    origin_path,
                    EventHandler.Action.ACTIVATE_SCENE,
                    flash_scn,
                )
                character.event_handler.register_event(
                    EventHandler.Event.PATH_ACTIVATED,
                    origin_path,
                    EventHandler.Action.SET_LAYER,
                    1,
                )
                character.event_handler.register_event(
                    EventHandler.Event.PATH_COMPLETE,
                    origin_path,
                    EventHandler.Action.DEACTIVATE_SCENE,
                    flash_scn,
                )
                inner_paths = 0
                total_inner_paths = 2
                while inner_paths < total_inner_paths:
                    next_coord = random.choice(swarm_area_coords)
                    inner_paths += 1
                    inner_path = character.motion.new_path(
                        path_id=str(len(character.motion.paths)),
                        speed=0.1,
                        ease=easing.in_out_sine,
                    )
                    inner_path.new_waypoint(next_coord, waypoint_id=str(len(character.motion.paths)))
            # create landing waypoint and scene
            input_path = character.motion.new_path(speed=0.3, ease=easing.in_out_quad)
            input_path.new_waypoint(character.input_coord)
            input_scn = character.animation.new_scene()
            for step in Gradient(self.config.flash_color, self.character_final_color_map[character], steps=10):
                input_scn.add_frame(character.input_symbol, 3, colors=ColorPair(fg=step))
            character.event_handler.register_event(
                EventHandler.Event.PATH_COMPLETE,
                input_path,
                EventHandler.Action.ACTIVATE_SCENE,
                input_scn,
            )
            character.event_handler.register_event(
                EventHandler.Event.PATH_COMPLETE,
                input_path,
                EventHandler.Action.SET_LAYER,
                0,
            )
            character.event_handler.register_event(
                EventHandler.Event.PATH_ACTIVATED,
                input_path,
                EventHandler.Action.ACTIVATE_SCENE,
                flash_scn,
            )
            character.motion.chain_paths(list(character.motion.paths.values()))
    self.call_next = True
    self.active_swarm_area = "0_swarm_area"

make_swarms(swarm_size)

Create swarms of characters.

Parameters:

Name Type Description Default
swarm_size int

The size of each swarm.

 required
Source code in terminaltexteffects/effects/effect_swarm.py
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
def make_swarms(self, swarm_size: int) -> None:
    """Create swarms of characters.

    Args:
        swarm_size (int): The size of each swarm.

    """
    unswarmed_characters = self.terminal.get_characters(
        sort=self.terminal.CharacterSort.BOTTOM_TO_TOP_RIGHT_TO_LEFT,
    )

    while unswarmed_characters:
        new_swarm: list[EffectCharacter] = []
        for _ in range(swarm_size):
            if unswarmed_characters:
                new_swarm.append(unswarmed_characters.pop())
            else:
                break
        self.swarms.append(new_swarm)
    final_swarm = self.swarms.pop()
    if len(final_swarm) < swarm_size // 2:
        self.swarms[-1].extend(final_swarm)
    else:
        self.swarms.append(final_swarm)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_swarm.py
31
32
33
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return Swarm, SwarmConfig
