SynthGrid

Quick Start

synthgrid.py

from terminaltexteffects.effects.effect_synthgrid import SynthGrid

effect = SynthGrid("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Create a grid which fills with characters dissolving into the final text.

Classes:

Name	Description
SynthGrid	Create a grid which fills with characters dissolving into the final text.
SynthGridConfig	Configuration for the SynthGrid effect.
SynthGridIterator	Iterates over the effect. Does not normally need to be called directly.

SynthGrid

Bases: BaseEffect[SynthGridConfig]

Create a grid which fills with characters dissolving into the final text.

Attributes:

Name	Type	Description
effect_config	SynthGridConfig	Configuration for the effect.
terminal_config	TerminalConfig	Configuration for the terminal.

Source code in terminaltexteffects/effects/effect_synthgrid.py

class SynthGrid(BaseEffect[SynthGridConfig]):
    """Create a grid which fills with characters dissolving into the final text.

    Attributes:
        effect_config (SynthGridConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.
    """

    _config_cls = SynthGridConfig
    _iterator_cls = SynthGridIterator

    def __init__(self, input_data: str) -> None:
        """Initialize the effect with the provided input data.

        Args:
            input_data (str): The input data to use for the effect."""
        super().__init__(input_data)

__init__(input_data)

Initialize the effect with the provided input data.

Parameters:

Name	Type	Description	Default
input_data	str	The input data to use for the effect.	required

Source code in terminaltexteffects/effects/effect_synthgrid.py

def __init__(self, input_data: str) -> None:
    """Initialize the effect with the provided input data.

    Args:
        input_data (str): The input data to use for the effect."""
    super().__init__(input_data)

SynthGridConfig dataclass

Bases: ArgsDataClass

Configuration for the SynthGrid effect.

Attributes:

Name	Type	Description
grid_gradient_stops	tuple[Color, ...]	Tuple of colors for the grid gradient.
grid_gradient_steps	tuple[int, ...]	Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
grid_gradient_direction	Direction	Direction of the gradient for the grid color.
text_gradient_stops	tuple[Color, ...]	Tuple of colors for the text gradient.
text_gradient_steps	tuple[int, ...]	Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
text_gradient_direction	Direction	Direction of the gradient for the text color.
grid_row_symbol	str	Symbol to use for grid row lines.
grid_column_symbol	str	Symbol to use for grid column lines.
text_generation_symbols	tuple[str, ...] | str	Tuple of characters for the text generation animation.
max_active_blocks	float	Maximum percentage of blocks to have active at any given time. For example, if set to 0.1, 10 percent of the blocks will be active at any given time. Valid values are 0 < n <= 1.

Source code in terminaltexteffects/effects/effect_synthgrid.py

@argclass(
    name="synthgrid",
    help="Create a grid which fills with characters dissolving into the final text.",
    description="synthgrid | Create a grid which fills with characters dissolving into the final text.",
    epilog="""Example: terminaltexteffects synthgrid --grid-gradient-stops CC00CC ffffff --grid-gradient-steps 12 --text-gradient-stops 8A008A 00D1FF FFFFFF --text-gradient-steps 12 --grid-row-symbol ─ --grid-column-symbol "│" --text-generation-symbols ░ ▒ ▓ --max-active-blocks 0.1""",
)
@dataclass
class SynthGridConfig(ArgsDataClass):
    """Configuration for the SynthGrid effect.

    Attributes:
        grid_gradient_stops (tuple[Color, ...]): Tuple of colors for the grid gradient.
        grid_gradient_steps (tuple[int, ...]): Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
        grid_gradient_direction (Gradient.Direction): Direction of the gradient for the grid color.
        text_gradient_stops (tuple[Color, ...]): Tuple of colors for the text gradient.
        text_gradient_steps (tuple[int, ...]): Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
        text_gradient_direction (Gradient.Direction): Direction of the gradient for the text color.
        grid_row_symbol (str): Symbol to use for grid row lines.
        grid_column_symbol (str): Symbol to use for grid column lines.
        text_generation_symbols (tuple[str, ...] | str): Tuple of characters for the text generation animation.
        max_active_blocks (float): Maximum percentage of blocks to have active at any given time. For example, if set to 0.1, 10 percent of the blocks will be active at any given time. Valid values are 0 < n <= 1."""

    grid_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--grid-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("CC00CC"), Color("ffffff")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the grid gradient.",
    )  # type: ignore[assignment]
    "tuple[Color, ...] : Tuple of colors for the grid gradient."

    grid_gradient_steps: tuple[int, ...] = ArgField(
        cmd_name="--grid-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation."

    grid_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--grid-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.DIAGONAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the gradient for the grid color.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the gradient for the grid color."

    text_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name=["--text-gradient-stops"],
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("8A008A"), Color("00D1FF"), Color("FFFFFF")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the text gradient.",
    )  # type: ignore[assignment]
    "tuple[Color, ...] : Tuple of colors for the text gradient."

    text_gradient_steps: tuple[int, ...] = ArgField(
        cmd_name="--text-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation."

    text_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--text-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.VERTICAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the gradient for the text color.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the gradient for the text color."

    grid_row_symbol: str = ArgField(
        cmd_name="--grid-row-symbol",
        type_parser=argvalidators.Symbol.type_parser,
        default="─",
        metavar=argvalidators.Symbol.METAVAR,
        help="Symbol to use for grid row lines.",
    )  # type: ignore[assignment]
    "str : Symbol to use for grid row lines."

    grid_column_symbol: str = ArgField(
        cmd_name="--grid-column-symbol",
        type_parser=argvalidators.Symbol.type_parser,
        default="│",
        metavar=argvalidators.Symbol.METAVAR,
        help="Symbol to use for grid column lines.",
    )  # type: ignore[assignment]
    "str : Symbol to use for grid column lines."

    text_generation_symbols: tuple[str, ...] = ArgField(
        cmd_name="--text-generation-symbols",
        type_parser=argvalidators.Symbol.type_parser,
        nargs="+",
        default=("░", "▒", "▓"),
        metavar=argvalidators.Symbol.METAVAR,
        help="Space separated, unquoted, list of characters for the text generation animation.",
    )  # type: ignore[assignment]
    "tuple[str, ...] : Tuple of characters for the text generation animation."

    max_active_blocks: float = ArgField(
        cmd_name="--max-active-blocks",
        type_parser=argvalidators.PositiveFloat.type_parser,
        default=0.1,
        metavar=argvalidators.PositiveFloat.METAVAR,
        help="Maximum percentage of blocks to have active at any given time. For example, if set to 0.1, 10 percent of the blocks will be active at any given time.",
    )  # type: ignore[assignment]
    "float : Maximum percentage of blocks to have active at any given time."

    @classmethod
    def get_effect_class(cls):
        return SynthGrid

grid_column_symbol: str = ArgField(cmd_name='--grid-column-symbol', type_parser=argvalidators.Symbol.type_parser, default='│', metavar=argvalidators.Symbol.METAVAR, help='Symbol to use for grid column lines.') class-attribute instance-attribute

str : Symbol to use for grid column lines.

grid_gradient_direction: Gradient.Direction = ArgField(cmd_name='--grid-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.DIAGONAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the gradient for the grid color.') class-attribute instance-attribute

Gradient.Direction : Direction of the gradient for the grid color.

grid_gradient_steps: tuple[int, ...] = ArgField(cmd_name='--grid-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

grid_gradient_stops: tuple[Color, ...] = ArgField(cmd_name=['--grid-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('CC00CC'), Color('ffffff')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the grid gradient.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the grid gradient.

grid_row_symbol: str = ArgField(cmd_name='--grid-row-symbol', type_parser=argvalidators.Symbol.type_parser, default='─', metavar=argvalidators.Symbol.METAVAR, help='Symbol to use for grid row lines.') class-attribute instance-attribute

str : Symbol to use for grid row lines.

max_active_blocks: float = ArgField(cmd_name='--max-active-blocks', type_parser=argvalidators.PositiveFloat.type_parser, default=0.1, metavar=argvalidators.PositiveFloat.METAVAR, help='Maximum percentage of blocks to have active at any given time. For example, if set to 0.1, 10 percent of the blocks will be active at any given time.') class-attribute instance-attribute

float : Maximum percentage of blocks to have active at any given time.

text_generation_symbols: tuple[str, ...] = ArgField(cmd_name='--text-generation-symbols', type_parser=argvalidators.Symbol.type_parser, nargs='+', default=('░', '▒', '▓'), metavar=argvalidators.Symbol.METAVAR, help='Space separated, unquoted, list of characters for the text generation animation.') class-attribute instance-attribute

tuple[str, ...] : Tuple of characters for the text generation animation.

text_gradient_direction: Gradient.Direction = ArgField(cmd_name='--text-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.VERTICAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the gradient for the text color.') class-attribute instance-attribute

Gradient.Direction : Direction of the gradient for the text color.

text_gradient_steps: tuple[int, ...] = ArgField(cmd_name='--text-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

text_gradient_stops: tuple[Color, ...] = ArgField(cmd_name=['--text-gradient-stops'], type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('8A008A'), Color('00D1FF'), Color('FFFFFF')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the text gradient.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the text gradient.

SynthGridIterator

Bases: BaseEffectIterator[SynthGridConfig]

Source code in terminaltexteffects/effects/effect_synthgrid.py

class SynthGridIterator(BaseEffectIterator[SynthGridConfig]):
    def __init__(self, effect: "SynthGrid") -> None:
        super().__init__(effect)
        self.pending_groups: list[tuple[int, list[EffectCharacter]]] = []
        self.grid_lines: list[GridLine] = []
        self.group_tracker: dict[int, int] = {}
        self.build()

    def find_even_gap(self, dimension: int) -> int:
        """Find the closest even gap to 20% of the longest dimension.

        Args:
            dimension (int): The longest dimension.

        Returns:
            int: The gap that is closest to 20% of the dimension length.
        """
        potential_gaps: list[int] = []
        dimension = dimension - 2
        if dimension <= 0:
            return 0
        for i in range(dimension, 4, -1):
            if dimension % i <= 1:
                potential_gaps.append(i)
        if not potential_gaps:
            return 4
        return min(potential_gaps, key=lambda x: abs(x - dimension // 5))

    def build(self) -> None:
        grid_gradient = Gradient(*self.config.grid_gradient_stops, steps=self.config.grid_gradient_steps)
        grid_gradient_mapping = grid_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.top, self.terminal.canvas.right, self.config.grid_gradient_direction
        )
        text_gradient = Gradient(*self.config.text_gradient_stops, steps=self.config.text_gradient_steps)
        text_gradient_mapping = text_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.top, self.terminal.canvas.right, self.config.text_gradient_direction
        )

        self.grid_lines.append(
            GridLine(
                self.terminal,
                self.config,
                Coord(self.terminal.canvas.left, self.terminal.canvas.bottom),
                "horizontal",
                grid_gradient_mapping,
            )
        )
        self.grid_lines.append(
            GridLine(
                self.terminal,
                self.config,
                Coord(self.terminal.canvas.left, self.terminal.canvas.top),
                "horizontal",
                grid_gradient_mapping,
            )
        )
        self.grid_lines.append(
            GridLine(
                self.terminal,
                self.config,
                Coord(self.terminal.canvas.left, self.terminal.canvas.bottom),
                "vertical",
                grid_gradient_mapping,
            )
        )
        self.grid_lines.append(
            GridLine(
                self.terminal,
                self.config,
                Coord(self.terminal.canvas.right, self.terminal.canvas.bottom),
                "vertical",
                grid_gradient_mapping,
            )
        )
        column_indexes: list[int] = []
        row_indexes: list[int] = []
        if self.terminal.canvas.top > 2 * self.terminal.canvas.right:
            row_gap = self.find_even_gap(self.terminal.canvas.top) + 1
            column_gap = row_gap * 2
        else:
            column_gap = self.find_even_gap(self.terminal.canvas.right) + 1
            row_gap = column_gap // 2

        for row_index in range(self.terminal.canvas.bottom + row_gap, self.terminal.canvas.top, max(row_gap, 1)):
            if self.terminal.canvas.top - row_index < 2:
                continue
            row_indexes.append(row_index)
            self.grid_lines.append(
                GridLine(
                    self.terminal,
                    self.config,
                    Coord(self.terminal.canvas.left, row_index),
                    "horizontal",
                    grid_gradient_mapping,
                )
            )
        for column_index in range(
            self.terminal.canvas.left + column_gap, self.terminal.canvas.right, max(column_gap, 1)
        ):
            if self.terminal.canvas.right - column_index < 2:
                continue
            column_indexes.append(column_index)
            self.grid_lines.append(
                GridLine(
                    self.terminal,
                    self.config,
                    Coord(column_index, self.terminal.canvas.bottom),
                    "vertical",
                    grid_gradient_mapping,
                )
            )
        row_indexes.append(self.terminal.canvas.top + 1)
        column_indexes.append(self.terminal.canvas.right + 1)
        prev_row_index = 1
        for row_index in row_indexes:
            prev_column_index = 1
            for column_index in column_indexes:
                coords_in_block: list[Coord] = []
                if row_index == self.terminal.canvas.top:  # make sure the top row is included
                    row_index += 1
                for row in range(prev_row_index, row_index):
                    for column in range(prev_column_index, column_index):
                        coords_in_block.append(Coord(column, row))
                characters_in_block: list[EffectCharacter] = []
                for coord in coords_in_block:
                    if coord in self.terminal.character_by_input_coord:
                        characters_in_block.append(self.terminal.character_by_input_coord[coord])
                if characters_in_block:
                    self.pending_groups.append((len(self.pending_groups), characters_in_block))
                prev_column_index = column_index
            prev_row_index = row_index
        for group_number, group in self.pending_groups:
            self.group_tracker[group_number] = 0
            for character in group:
                dissolve_scn = character.animation.new_scene()
                for _ in range(random.randint(15, 30)):
                    dissolve_scn.add_frame(
                        random.choice(self.config.text_generation_symbols),
                        3,
                        color=random.choice(text_gradient.spectrum),
                    )
                dissolve_scn.add_frame(character.input_symbol, 1, color=text_gradient_mapping[character.input_coord])
                character.animation.activate_scene(dissolve_scn)
                character.event_handler.register_event(
                    EventHandler.Event.SCENE_COMPLETE,
                    dissolve_scn,
                    EventHandler.Action.CALLBACK,
                    EventHandler.Callback(self.update_group_tracker, group_number),
                )
        random.shuffle(self.pending_groups)
        self._phase = "grid_expand"
        self._total_group_count = len(self.pending_groups)
        if not self._total_group_count:
            for character in self.terminal.get_characters():
                self.terminal.set_character_visibility(character, True)
                self.active_characters.append(character)
        self._active_groups: int = 0

    def update_group_tracker(self, character: EffectCharacter, *args) -> None:
        self.group_tracker[args[0]] -= 1

    def __next__(self) -> str:
        if self.pending_groups or self.active_characters or self._phase != "complete":
            if self._phase == "grid_expand":
                if not all([grid_line.is_extended() for grid_line in self.grid_lines]):
                    for grid_line in self.grid_lines:
                        if not grid_line.is_extended():
                            grid_line.extend()
                else:
                    self._phase = "add_chars"
            elif self._phase == "add_chars":
                if (
                    self.pending_groups
                    and self._active_groups < self._total_group_count * self.config.max_active_blocks
                ):
                    group_number, next_group = self.pending_groups.pop(0)
                    for char in next_group:
                        self.terminal.set_character_visibility(char, True)
                        self.active_characters.append(char)
                        self.group_tracker[group_number] += 1
                if not self.pending_groups and not self.active_characters and not self._active_groups:
                    self._phase = "collapse"
            elif self._phase == "collapse":
                if not all([grid_line.is_collapsed() for grid_line in self.grid_lines]):
                    for grid_line in self.grid_lines:
                        if not grid_line.is_collapsed():
                            grid_line.collapse()
                else:
                    self._phase = "complete"
            self.update()
            self._active_groups = 0
            for _, active_count in self.group_tracker.items():
                if active_count:
                    self._active_groups += 1
            return self.frame
        else:
            raise StopIteration

find_even_gap(dimension)

Find the closest even gap to 20% of the longest dimension.

Parameters:

Name	Type	Description	Default
dimension	int	The longest dimension.	required

Returns:

Name	Type	Description
int	int	The gap that is closest to 20% of the dimension length.

Source code in terminaltexteffects/effects/effect_synthgrid.py

def find_even_gap(self, dimension: int) -> int:
    """Find the closest even gap to 20% of the longest dimension.

    Args:
        dimension (int): The longest dimension.

    Returns:
        int: The gap that is closest to 20% of the dimension length.
    """
    potential_gaps: list[int] = []
    dimension = dimension - 2
    if dimension <= 0:
        return 0
    for i in range(dimension, 4, -1):
        if dimension % i <= 1:
            potential_gaps.append(i)
    if not potential_gaps:
        return 4
    return min(potential_gaps, key=lambda x: abs(x - dimension // 5))
