Waves

Demo

Quick Start

waves.py
from terminaltexteffects.effects.effect_waves import Waves

effect = Waves("YourTextHere")
with effect.terminal_output() as terminal:
    for frame in effect:
        terminal.print(frame)

Waves travel across the terminal leaving behind the characters.

Classes:

Name Description
Waves

Creates waves that travel across the terminal, leaving behind the characters.
WavesConfig

Configuration for the Waves effect.
WavesIterator

Iterates over the effect. Does not normally need to be called directly.

Waves

Bases: BaseEffect[WavesConfig]

Creates waves that travel across the terminal, leaving behind the characters.

Attributes:

Name Type Description
effect_config ExpandConfig

Configuration for the effect.
terminal_config TerminalConfig

Configuration for the terminal.
Source code in terminaltexteffects/effects/effect_waves.py
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
class Waves(BaseEffect[WavesConfig]):
    """Creates waves that travel across the terminal, leaving behind the characters.

    Attributes:
        effect_config (ExpandConfig): Configuration for the effect.
        terminal_config (TerminalConfig): Configuration for the terminal.

    """

    @property
    def _config_cls(self) -> type[WavesConfig]:
        return WavesConfig

    @property
    def _iterator_cls(self) -> type[WavesIterator]:
        return WavesIterator

WavesConfig dataclass

Bases: ArgsDataClass

Configuration for the Waves effect.

Attributes:

Name Type Description
wave_symbols tuple[str, ...] | str

Symbols to use for the wave animation. Multi-character strings will be used in sequence to create an animation.
wave_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.
wave_gradient_steps tuple[int, ...]

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
wave_count int

Number of waves to generate. Valid values are n > 0.
wave_length int

The number of frames for each step of the wave. Higher wave-lengths will create a slower wave. Valid values are n > 0.
wave_direction Literal['column_left_to_right', 'column_right_to_left', 'row_top_to_bottom', 'row_bottom_to_top', 'center_to_outside', 'outside_to_center']

Direction of the wave.
wave_easing EasingFunction

Easing function to use for wave travel.
final_gradient_stops tuple[Color, ...]

Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.
final_gradient_steps tuple[int, ...] | int

Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation. Valid values are n > 0.
final_gradient_direction Direction

Direction of the final gradient.
Source code in terminaltexteffects/effects/effect_waves.py
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
@argclass(
    name="waves",
    help="Waves travel across the terminal leaving behind the characters.",
    description="waves | Waves travel across the terminal leaving behind the characters.",
    epilog=(
        f"{argvalidators.EASING_EPILOG} Example: terminaltexteffects waves --wave-symbols ▁ ▂ ▃ ▄ ▅ ▆ ▇ █ "
        "▇ ▆ ▅ ▄ ▃ ▂ ▁ --wave-gradient-stops f0ff65 ffb102 31a0d4 ffb102 f0ff65 --wave-gradient-steps 6 "
        "--final-gradient-stops ffb102 31a0d4 f0ff65 --final-gradient-steps 12 --wave-count 7 --wave-length 2 "
        "--wave-easing IN_OUT_SINE"
    ),
)
@dataclass
class WavesConfig(ArgsDataClass):
    """Configuration for the Waves effect.

    Attributes:
        wave_symbols (tuple[str, ...] | str): Symbols to use for the wave animation. Multi-character strings will be
            used in sequence to create an animation.
        wave_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color is
            provided, the characters will be displayed in that color.
        wave_gradient_steps (tuple[int, ...]): Tuple of the number of gradient steps to use. More steps will create a
            smoother and longer gradient animation. Valid values are n > 0.
        wave_count (int): Number of waves to generate. Valid values are n > 0.
        wave_length (int): The number of frames for each step of the wave. Higher wave-lengths will create a slower
            wave. Valid values are n > 0.
        wave_direction (typing.Literal['column_left_to_right','column_right_to_left','row_top_to_bottom','row_bottom_to_top','center_to_outside','outside_to_center']): Direction of the wave.
        wave_easing (easing.EasingFunction): Easing function to use for wave travel.
        final_gradient_stops (tuple[Color, ...]): Tuple of colors for the final color gradient. If only one color is
            provided, the characters will be displayed in that color.
        final_gradient_steps (tuple[int, ...] | int): Tuple of the number of gradient steps to use. More steps will
            create a smoother and longer gradient animation. Valid values are n > 0.
        final_gradient_direction (Gradient.Direction): Direction of the final gradient.

    """  # noqa: E501

    wave_symbols: tuple[str, ...] = ArgField(
        cmd_name="--wave-symbols",
        type_parser=argvalidators.Symbol.type_parser,
        default=("▁", "▂", "▃", "▄", "▅", "▆", "▇", "█", "▇", "▆", "▅", "▄", "▃", "▂", "▁"),
        nargs="+",
        metavar=argvalidators.Symbol.METAVAR,
        help="Symbols to use for the wave animation. Multi-character strings will be used in sequence to create an "
        "animation.",
    )  # type: ignore[assignment]
    (
        "tuple[str, ...] : Symbols to use for the wave animation. Multi-character strings will be used in sequence to "
        "create an animation."
    )

    wave_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name="--wave-gradient-stops",
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("#f0ff65"), Color("#ffb102"), Color("#31a0d4"), Color("#ffb102"), Color("#f0ff65")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If "
        "only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    wave_gradient_steps: tuple[int, ...] = ArgField(
        cmd_name="--wave-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=(6,),
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create a "
        "smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] : Tuple of the number of gradient steps to use. More steps will create a smoother and "
        "longer gradient animation."
    )

    wave_count: int = ArgField(
        cmd_name="--wave-count",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=7,
        help="Number of waves to generate. n > 0.",
    )  # type: ignore[assignment]
    "int : Number of waves to generate. n > 0."

    wave_length: int = ArgField(
        cmd_name="--wave-length",
        type_parser=argvalidators.PositiveInt.type_parser,
        default=2,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="The number of frames for each step of the wave. Higher wave-lengths will create a slower wave.",
    )  # type: ignore[assignment]
    "int : The number of frames for each step of the wave. Higher wave-lengths will create a slower wave."

    wave_direction: typing.Literal[
        "column_left_to_right",
        "column_right_to_left",
        "row_top_to_bottom",
        "row_bottom_to_top",
        "center_to_outside",
        "outside_to_center",
    ] = ArgField(
        cmd_name="--wave-direction",
        default="column_left_to_right",
        help="Direction of the wave.",
        choices=[
            "column_left_to_right",
            "column_right_to_left",
            "row_top_to_bottom",
            "row_bottom_to_top",
            "center_to_outside",
            "outside_to_center",
        ],
    )  # type: ignore[assignment]
    "typing.Literal['column_left_to_right','column_right_to_left','row_top_to_bottom','row_bottom_to_top','center_to_outside','outside_to_center']"

    wave_easing: easing.EasingFunction = ArgField(
        cmd_name="--wave-easing",
        type_parser=argvalidators.Ease.type_parser,
        default=easing.in_out_sine,
        help="Easing function to use for wave travel.",
    )  # type: ignore[assignment]
    "easing.EasingFunction : Easing function to use for wave travel."

    final_gradient_stops: tuple[Color, ...] = ArgField(
        cmd_name="--final-gradient-stops",
        type_parser=argvalidators.ColorArg.type_parser,
        nargs="+",
        default=(Color("#ffb102"), Color("#31a0d4"), Color("#f0ff65")),
        metavar=argvalidators.ColorArg.METAVAR,
        help="Space separated, unquoted, list of colors for the character gradient (applied across the canvas). "
        "If only one color is provided, the characters will be displayed in that color.",
    )  # type: ignore[assignment]
    (
        "tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the "
        "characters will be displayed in that color."
    )

    final_gradient_steps: tuple[int, ...] | int = ArgField(
        cmd_name="--final-gradient-steps",
        type_parser=argvalidators.PositiveInt.type_parser,
        nargs="+",
        default=12,
        metavar=argvalidators.PositiveInt.METAVAR,
        help="Space separated, unquoted, list of the number of gradient steps to use. More steps will create "
        "a smoother and longer gradient animation.",
    )  # type: ignore[assignment]
    (
        "tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps "
        "will create a smoother and longer gradient animation."
    )

    final_gradient_direction: Gradient.Direction = ArgField(
        cmd_name="--final-gradient-direction",
        type_parser=argvalidators.GradientDirection.type_parser,
        default=Gradient.Direction.DIAGONAL,
        metavar=argvalidators.GradientDirection.METAVAR,
        help="Direction of the final gradient.",
    )  # type: ignore[assignment]
    "Gradient.Direction : Direction of the final gradient."

    @classmethod
    def get_effect_class(cls) -> type[Waves]:
        """Get the effect class associated with this configuration."""
        return Waves

final_gradient_direction = ArgField(cmd_name='--final-gradient-direction', type_parser=argvalidators.GradientDirection.type_parser, default=Gradient.Direction.DIAGONAL, metavar=argvalidators.GradientDirection.METAVAR, help='Direction of the final gradient.') class-attribute instance-attribute

Gradient.Direction : Direction of the final gradient.

final_gradient_steps = ArgField(cmd_name='--final-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=12, metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] | int : Int or Tuple of ints for the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

final_gradient_stops = ArgField(cmd_name='--final-gradient-stops', type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('#ffb102'), Color('#31a0d4'), Color('#f0ff65')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

wave_count = ArgField(cmd_name='--wave-count', type_parser=argvalidators.PositiveInt.type_parser, default=7, help='Number of waves to generate. n > 0.') class-attribute instance-attribute

int : Number of waves to generate. n > 0.

wave_direction = ArgField(cmd_name='--wave-direction', default='column_left_to_right', help='Direction of the wave.', choices=['column_left_to_right', 'column_right_to_left', 'row_top_to_bottom', 'row_bottom_to_top', 'center_to_outside', 'outside_to_center']) class-attribute instance-attribute

typing.Literal['column_left_to_right','column_right_to_left','row_top_to_bottom','row_bottom_to_top','center_to_outside','outside_to_center']

wave_easing = ArgField(cmd_name='--wave-easing', type_parser=argvalidators.Ease.type_parser, default=easing.in_out_sine, help='Easing function to use for wave travel.') class-attribute instance-attribute

easing.EasingFunction : Easing function to use for wave travel.

wave_gradient_steps = ArgField(cmd_name='--wave-gradient-steps', type_parser=argvalidators.PositiveInt.type_parser, nargs='+', default=(6,), metavar=argvalidators.PositiveInt.METAVAR, help='Space separated, unquoted, list of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.') class-attribute instance-attribute

tuple[int, ...] : Tuple of the number of gradient steps to use. More steps will create a smoother and longer gradient animation.

wave_gradient_stops = ArgField(cmd_name='--wave-gradient-stops', type_parser=argvalidators.ColorArg.type_parser, nargs='+', default=(Color('#f0ff65'), Color('#ffb102'), Color('#31a0d4'), Color('#ffb102'), Color('#f0ff65')), metavar=argvalidators.ColorArg.METAVAR, help='Space separated, unquoted, list of colors for the character gradient (applied across the canvas). If only one color is provided, the characters will be displayed in that color.') class-attribute instance-attribute

tuple[Color, ...] : Tuple of colors for the final color gradient. If only one color is provided, the characters will be displayed in that color.

wave_length = ArgField(cmd_name='--wave-length', type_parser=argvalidators.PositiveInt.type_parser, default=2, metavar=argvalidators.PositiveInt.METAVAR, help='The number of frames for each step of the wave. Higher wave-lengths will create a slower wave.') class-attribute instance-attribute

int : The number of frames for each step of the wave. Higher wave-lengths will create a slower wave.

wave_symbols = ArgField(cmd_name='--wave-symbols', type_parser=argvalidators.Symbol.type_parser, default=('▁', '▂', '▃', '▄', '▅', '▆', '▇', '█', '▇', '▆', '▅', '▄', '▃', '▂', '▁'), nargs='+', metavar=argvalidators.Symbol.METAVAR, help='Symbols to use for the wave animation. Multi-character strings will be used in sequence to create an animation.') class-attribute instance-attribute

tuple[str, ...] : Symbols to use for the wave animation. Multi-character strings will be used in sequence to create an animation.

get_effect_class() classmethod

Get the effect class associated with this configuration.

Source code in terminaltexteffects/effects/effect_waves.py
186
187
188
189
@classmethod
def get_effect_class(cls) -> type[Waves]:
    """Get the effect class associated with this configuration."""
    return Waves

WavesIterator

Bases: BaseEffectIterator[WavesConfig]

Iterator for the Waves effect.

Source code in terminaltexteffects/effects/effect_waves.py
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
class WavesIterator(BaseEffectIterator[WavesConfig]):
    """Iterator for the Waves effect."""

    def __init__(self, effect: Waves) -> None:
        """Initialize the iterator with the provided effect.

        Args:
            effect (Waves): The effect to iterate over.

        """
        super().__init__(effect)
        self.pending_columns: list[list[EffectCharacter]] = []
        self.character_final_color_map: dict[EffectCharacter, Color] = {}
        self.build()

    def build(self) -> None:
        """Build the effect."""
        final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
        final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
            self.terminal.canvas.text_bottom,
            self.terminal.canvas.text_top,
            self.terminal.canvas.text_left,
            self.terminal.canvas.text_right,
            self.config.final_gradient_direction,
        )
        wave_gradient = Gradient(*self.config.wave_gradient_stops, steps=self.config.wave_gradient_steps)
        for character in self.terminal.get_characters():
            self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
            wave_scn = character.animation.new_scene()
            wave_scn.ease = self.config.wave_easing
            for _ in range(self.config.wave_count):
                wave_scn.apply_gradient_to_symbols(
                    self.config.wave_symbols,
                    duration=self.config.wave_length,
                    fg_gradient=wave_gradient,
                )
            final_scn = character.animation.new_scene()
            for step in Gradient(
                wave_gradient.spectrum[-1],
                self.character_final_color_map[character],
                steps=self.config.final_gradient_steps,
            ):
                final_scn.add_frame(character.input_symbol, 10, colors=ColorPair(fg=step))
            character.event_handler.register_event(
                EventHandler.Event.SCENE_COMPLETE,
                wave_scn,
                EventHandler.Action.ACTIVATE_SCENE,
                final_scn,
            )
            character.animation.activate_scene(wave_scn)
        grouping_map = {
            "column_left_to_right": self.terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
            "column_right_to_left": self.terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
            "row_top_to_bottom": self.terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
            "row_bottom_to_top": self.terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
            "center_to_outside": self.terminal.CharacterGroup.CENTER_TO_OUTSIDE_DIAMONDS,
            "outside_to_center": self.terminal.CharacterGroup.OUTSIDE_TO_CENTER_DIAMONDS,
        }

        for column in self.terminal.get_characters_grouped(grouping=grouping_map[self.config.wave_direction]):
            self.pending_columns.append(column)

    def __next__(self) -> str:
        """Return the next frame in the animation."""
        if self.pending_columns or self.active_characters:
            if self.pending_columns:
                next_column = self.pending_columns.pop(0)
                for character in next_column:
                    self.terminal.set_character_visibility(character, is_visible=True)
                    self.active_characters.add(character)
            self.update()
            return self.frame
        raise StopIteration

__init__(effect)

Initialize the iterator with the provided effect.

Parameters:

Name Type Description Default
effect Waves

The effect to iterate over.

 required
Source code in terminaltexteffects/effects/effect_waves.py
195
196
197
198
199
200
201
202
203
204
205
def __init__(self, effect: Waves) -> None:
    """Initialize the iterator with the provided effect.

    Args:
        effect (Waves): The effect to iterate over.

    """
    super().__init__(effect)
    self.pending_columns: list[list[EffectCharacter]] = []
    self.character_final_color_map: dict[EffectCharacter, Color] = {}
    self.build()

__next__()

Return the next frame in the animation.

Source code in terminaltexteffects/effects/effect_waves.py
254
255
256
257
258
259
260
261
262
263
264
def __next__(self) -> str:
    """Return the next frame in the animation."""
    if self.pending_columns or self.active_characters:
        if self.pending_columns:
            next_column = self.pending_columns.pop(0)
            for character in next_column:
                self.terminal.set_character_visibility(character, is_visible=True)
                self.active_characters.add(character)
        self.update()
        return self.frame
    raise StopIteration

build()

Build the effect.

Source code in terminaltexteffects/effects/effect_waves.py
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
def build(self) -> None:
    """Build the effect."""
    final_gradient = Gradient(*self.config.final_gradient_stops, steps=self.config.final_gradient_steps)
    final_gradient_mapping = final_gradient.build_coordinate_color_mapping(
        self.terminal.canvas.text_bottom,
        self.terminal.canvas.text_top,
        self.terminal.canvas.text_left,
        self.terminal.canvas.text_right,
        self.config.final_gradient_direction,
    )
    wave_gradient = Gradient(*self.config.wave_gradient_stops, steps=self.config.wave_gradient_steps)
    for character in self.terminal.get_characters():
        self.character_final_color_map[character] = final_gradient_mapping[character.input_coord]
        wave_scn = character.animation.new_scene()
        wave_scn.ease = self.config.wave_easing
        for _ in range(self.config.wave_count):
            wave_scn.apply_gradient_to_symbols(
                self.config.wave_symbols,
                duration=self.config.wave_length,
                fg_gradient=wave_gradient,
            )
        final_scn = character.animation.new_scene()
        for step in Gradient(
            wave_gradient.spectrum[-1],
            self.character_final_color_map[character],
            steps=self.config.final_gradient_steps,
        ):
            final_scn.add_frame(character.input_symbol, 10, colors=ColorPair(fg=step))
        character.event_handler.register_event(
            EventHandler.Event.SCENE_COMPLETE,
            wave_scn,
            EventHandler.Action.ACTIVATE_SCENE,
            final_scn,
        )
        character.animation.activate_scene(wave_scn)
    grouping_map = {
        "column_left_to_right": self.terminal.CharacterGroup.COLUMN_LEFT_TO_RIGHT,
        "column_right_to_left": self.terminal.CharacterGroup.COLUMN_RIGHT_TO_LEFT,
        "row_top_to_bottom": self.terminal.CharacterGroup.ROW_TOP_TO_BOTTOM,
        "row_bottom_to_top": self.terminal.CharacterGroup.ROW_BOTTOM_TO_TOP,
        "center_to_outside": self.terminal.CharacterGroup.CENTER_TO_OUTSIDE_DIAMONDS,
        "outside_to_center": self.terminal.CharacterGroup.OUTSIDE_TO_CENTER_DIAMONDS,
    }

    for column in self.terminal.get_characters_grouped(grouping=grouping_map[self.config.wave_direction]):
        self.pending_columns.append(column)

get_effect_and_args()

Get the effect class and its configuration class.

Source code in terminaltexteffects/effects/effect_waves.py
20
21
22
def get_effect_and_args() -> tuple[type[typing.Any], type[ArgsDataClass]]:
    """Get the effect class and its configuration class."""
    return Waves, WavesConfig
