Spin, step 4: Shading and the back side
Every character has been the same color so far. In this step each one is colored by how squarely it faces you: dark when edge-on or turned away, its gradient color facing forward. The turning sheet now reads as a lit surface.
3D chapters used: Light and shading, Depth and hidden surfaces.
Update the module
Replace myspin.py with this version:
"""MySpin, tutorial step 4: shading and the back side.
Each character's color follows how squarely it faces the light in front of the sheet: dark when edge-on or turned
away, its gradient color facing forward. Later steps build it up into the Spin effect.
"""
from __future__ import annotations
from dataclasses import dataclass
from terminaltexteffects import Body, Color, ColorPair, EffectCharacter, Gradient, Scene, Vec3, easing
from terminaltexteffects.engine.base_config import BaseConfig
from terminaltexteffects.engine.base_effect import BaseEffect, BaseEffectIterator
from terminaltexteffects.utils import argutils
START_DISTANCE = 200
"""How far behind the canvas the sheet starts, in columns."""
SPIN_FRAMES = 240
"""Frames from the start until the sheet lands."""
SHADOW_COLOR = Color("#303030")
"""Color of the text when it faces away from the light."""
FINAL_GRADIENT = Gradient(Color("#8A008A"), Color("#00D1FF"), Color("#FFFFFF"), steps=12)
"""Colors of the text facing the light, top to bottom."""
HIDE_BACK = False
"""Whether to hide the text while its back faces the viewer, instead of showing it mirrored in shadow."""
def get_effect_resources() -> tuple[str, type[BaseEffect], type[BaseConfig]]:
"""Return the command name, effect class, and configuration class TTE registers."""
return "myspin", MySpin, MySpinConfig
@dataclass
class MySpinConfig(BaseConfig):
"""Configuration for the MySpin effect. It has no options yet."""
parser_spec = argutils.ParserSpec(
name="myspin",
help="The text tumbles in from the distance as a flat sheet, spins, and settles into place.",
description="myspin | The text tumbles in from the distance as a flat sheet, spins, and settles into place.",
epilog="Example: tte myspin",
)
class MySpinIterator(BaseEffectIterator[MySpinConfig]):
"""Produce the frames of the MySpin effect."""
def __init__(self, effect: MySpin) -> None:
"""Move the text plane far behind the canvas and queue its approach."""
super().__init__(effect)
self.final_colors: dict[EffectCharacter, ColorPair] = {}
self.world = self.terminal.world
self.build()
def build(self) -> None:
"""Shade every visible character, move the text plane back, and queue the spin and approach."""
world = self.world
world.camera.set_perspective(1)
world.set_light("front")
final_gradient_mapping = FINAL_GRADIENT.build_coordinate_color_mapping(
self.terminal.canvas.text_bottom,
self.terminal.canvas.text_top,
self.terminal.canvas.text_left,
self.terminal.canvas.text_right,
Gradient.Direction.VERTICAL,
)
characters = [character for character in self.terminal.get_characters() if character.input_symbol != " "]
for character in characters:
final_color = final_gradient_mapping[character.input_coord]
self.final_colors[character] = ColorPair(fg=final_color)
# The light on its spot picks the frame: shadow when the text faces away, the final color facing
# the light.
scene = character.animation.new_scene(sync=Scene.SyncMetric.LIGHT)
scene.apply_gradient_to_symbols(
character.input_symbol, 1, fg_gradient=Gradient(SHADOW_COLOR, final_color, steps=10)
)
character.animation.activate_scene(scene)
self.terminal.set_character_visibility(character, is_visible=True)
self.active_characters.add(character)
self.sheet = world.text_plane
self.sheet.hide_facing_away = HIDE_BACK
self.sheet.position = Vec3(0, 0, -START_DISTANCE)
self.sheet.spin("y", turns=2, frames=SPIN_FRAMES, ease=easing.out_cubic)
approach = self.sheet.motion.new_path(speed=START_DISTANCE / SPIN_FRAMES, ease=easing.out_cubic)
approach.new_waypoint(Vec3(0, 0, 0))
self.sheet.motion.activate_path(approach)
self.sheet.on_complete(self.finish)
def finish(self, sheet: Body) -> None:
"""Put the text plane back at rest and show the characters in their final colors."""
sheet.reset()
for character, colors in self.final_colors.items():
character.animation.deactivate_scene()
character.animation.set_appearance(character.input_symbol, colors)
def __next__(self) -> str:
"""Move the text plane one frame; the characters on it move with it."""
if self.world.animating or self.active_characters:
self.update()
return self.frame
raise StopIteration
class MySpin(BaseEffect[MySpinConfig]):
"""The text tumbles in from the distance as a flat sheet, spins, and settles into place."""
@property
def _config_cls(self) -> type[MySpinConfig]:
return MySpinConfig
@property
def _iterator_cls(self) -> type[MySpinIterator]:
return MySpinIterator
What changed
A light in front
world.set_light("front") points the light along +z, from behind the viewer toward the canvas. It's a direction,
not a lamp at a position, so a surface turned toward the viewer is turned toward the light too. How lit the sheet is
and how squarely it faces you are nearly the same thing here. They match exactly in an orthographic view; with
perspective, the parts of the sheet away from the center are seen at a slight angle.
Scenes synced to the light
Every character on a surface has a light reading, character.view.light: 1 when its spot faces the light squarely,
0 when edge-on or facing away. A scene created with sync=Scene.SyncMetric.LIGHT picks its frame from that reading instead of playing
in order.
Each character gets a scene with one frame per color of a gradient, from SHADOW_COLOR to its final color. Its final
color comes from FINAL_GRADIENT mapped over the text from top to bottom, as in most built-in effects.
The back side
When the sheet faces away, its light reading is 0, so the mirrored text shows in the shadow color. That reads as the
back of the sheet. HIDE_BACK = True would set hide_facing_away on the text plane instead, which hides each
character while its spot faces away from you.
Final colors
on_complete(self.finish) calls finish when the sheet's last tween ends. finish resets the plane, then stops each
scene and sets the character to its final color. Without this, each character would keep whichever frame its scene
showed last. The scenes keep the characters in active_characters until then, so __next__ runs until finish has
stopped them.
Run it
Next step
Step 5 starts the sheet at a random tilt and lets it settle.
