Phases and staggered starts

Many effects happen in stages: characters appear, move into place, and then the finished text does something together. Within a stage, groups of characters often start one after another rather than all at once. This page shows how to structure both in an iterator. Built-in effects that use this pattern include Beams, Blackhole, and Middleout.

The Gather example

Gather runs in three phases:

1. Scatter: every character sits at a random position as a gray dot, for 30 ticks.
2. Gather: groups of characters, one row at a time by default, travel home every 4 ticks, turning from dots into their symbols on the way.
3. Flash: when every character is home, the whole text flashes from white to blue.

Save it as gather.py in your community effects directory:

gather.py

"""Gather: scattered dots gather into the text one group at a time, then the text flashes.

An Effect Guide example for the Phases and staggered starts pattern.
"""

from __future__ import annotations

from dataclasses import dataclass

from terminaltexteffects import CharacterOrder, Color, ColorPair, EffectCharacter, Gradient, Scene, easing
from terminaltexteffects.engine.base_config import BaseConfig
from terminaltexteffects.engine.base_effect import BaseEffect, BaseEffectIterator
from terminaltexteffects.utils import argutils

DOT_COLOR = Color("#606060")
TEXT_COLOR = Color("#40c0ff")
ARRIVE = Gradient(DOT_COLOR, TEXT_COLOR, steps=8)
FLASH = Gradient(Color("#ffffff"), TEXT_COLOR, steps=10)
SCATTER_TICKS = 30
TICKS_BETWEEN_GROUPS = 4


def get_effect_resources() -> tuple[str, type[BaseEffect], type[BaseConfig]]:
    """Return the command name, effect class, and configuration class TTE registers."""
    return "gather", Gather, GatherConfig


@dataclass
class GatherConfig(BaseConfig):
    """Configuration for the Gather effect."""

    parser_spec = argutils.ParserSpec(
        name="gather",
        help="Scattered dots gather into the text one group at a time, then the text flashes.",
        description="gather | Scattered dots gather into the text one group at a time, then the text flashes.",
        epilog="Example: tte gather --gather-order column_left_to_right",
    )
    gather_order: CharacterOrder = argutils.ArgSpec(
        name="--gather-order",
        type=argutils.CharacterOrderArg.type_parser,
        default=CharacterOrder.ROW_TOP_TO_BOTTOM,
        metavar=" ".join(argutils.CharacterOrderArg.METAVAR),
        help="Order in which groups of characters gather.",
    )  # pyright: ignore[reportAssignmentType]
    "CharacterOrder : Order in which groups of characters gather."


class GatherIterator(BaseEffectIterator[GatherConfig]):
    """Produce the frames of the Gather effect, one phase after another."""

    def __init__(self, effect: Gather) -> None:
        """Scatter the characters as dots and queue the groups that gather."""
        super().__init__(effect)
        self.phase = "scatter"
        self.ticks_in_phase = 0
        self.pending_groups = self.terminal.get_characters_grouped(order=self.config.gather_order)
        self.pending_groups.reverse()  # So pop() takes the first group.
        for character in self.terminal.get_characters():
            character.motion.set_coordinate(self.terminal.canvas.random_coord())
            character.animation.set_appearance(".", ColorPair(fg=DOT_COLOR))
            self.terminal.set_character_visibility(character, is_visible=True)

    def start_gathering(self, character: EffectCharacter) -> None:
        """Send a character home, turning from a dot into its symbol on the way."""
        path = character.motion.new_path(speed=0.8, ease=easing.in_out_sine)
        path.new_waypoint(character.input_coord)
        character.motion.activate_path(path)
        scene = character.animation.new_scene(sync=Scene.SyncMetric.DISTANCE)
        scene.apply_gradient_to_symbols((".", "o", character.input_symbol), 1, fg_gradient=ARRIVE)
        character.animation.activate_scene(scene)
        self.active_characters.add(character)

    def __next__(self) -> str:
        """Run the current phase for one tick and return the frame."""
        self.ticks_in_phase += 1
        if self.phase == "scatter":
            if self.ticks_in_phase == SCATTER_TICKS:
                self.phase, self.ticks_in_phase = "gather", 0
        elif self.phase == "gather":
            if self.pending_groups and self.ticks_in_phase % TICKS_BETWEEN_GROUPS == 1:
                for character in self.pending_groups.pop():
                    self.start_gathering(character)
            if not self.pending_groups and not self.active_characters:
                self.start_flash()
        elif self.phase == "flash" and not self.active_characters:
            raise StopIteration
        self.update()
        return self.frame

    def start_flash(self) -> None:
        """Flash every character from white to the text color."""
        self.phase, self.ticks_in_phase = "flash", 0
        for character in self.terminal.get_characters():
            scene = character.animation.new_scene()
            scene.apply_gradient_to_symbols(character.input_symbol, 3, fg_gradient=FLASH)
            character.animation.activate_scene(scene)
            self.active_characters.add(character)


class Gather(BaseEffect[GatherConfig]):
    """Scattered dots gather into the text one group at a time, then the text flashes."""

    @property
    def _config_cls(self) -> type[GatherConfig]:
        return GatherConfig

    @property
    def _iterator_cls(self) -> type[GatherIterator]:
        return GatherIterator

tte --input-file concept_input.txt gather

A phase is state in the iterator

The iterator keeps two attributes: phase, the name of the current phase, and ticks_in_phase, the number of ticks since that phase began. __next__ runs the code for the current phase, updates the characters, and returns the frame, so every phase still produces one frame per call.

Each phase decides when it ends, and starts the next one:

• Scatter ends after a fixed number of ticks. Nothing is active, so the scattered dots stay still: visible characters are drawn whether or not they are active.
• Gather ends when no groups are waiting and active_characters is empty, meaning every character has finished its path and scene.
• Flash gives every character a new scene and adds them all to active_characters again. When they are all inactive, the effect raises StopIteration.

Checking active_characters is the usual way to wait for a phase's motion and animation to finish. If a phase needs to wait for something else, such as a particular character reaching a waypoint, set a flag from an event callback (see Events) and check the flag in __next__.

Keep phase changes in one place, as Gather does with start_flash(), so the setup for each phase is easy to find. For effects with many phases, an Enum of phase names avoids typos in the strings.

Staggered starts

terminal.get_characters_grouped(order=...) splits the characters into groups, such as rows, columns, or diagonals (see Characters). Gather reverses the list once, so pop() takes the groups in order, and releases the next group every TICKS_BETWEEN_GROUPS ticks.

With --gather-order, any order can drive the stagger:

tte --input-file concept_input.txt gather --gather-order column_left_to_right

Other common ways to stagger starts:

• Release a fixed number of characters from a shuffled list each tick, as MySpray does in step 2.
• Start every character at once, but give each a different speed or a hold_time, so arrival times differ.
• Release a group when the previous group's path completes, using a PATH_COMPLETE callback.

Where to go next

• The frame loop explains when an effect ends and what update() does.
• Animation explains the synced scene each character plays as it gathers.
