Spin, step 5: Tumbling in and settling
The sheet has always started upright. In this step it starts at a random orientation and unwinds the tilt while it spins, so it tumbles in and still lands exactly on the text.
3D chapters used: Rotation.
Update the module
Replace myspin.py with this version:
myspin.py
"""MySpin, tutorial step 5: tumbling in and settling.
The sheet starts in a random orientation and unwinds its tilt as it spins, landing exactly on the input cells. The
next step turns the constants into options.
"""
from __future__ import annotations
from dataclasses import dataclass
from terminaltexteffects import Color, ColorPair, EffectCharacter, Gradient, Scene, easing
from terminaltexteffects.engine.base_config import BaseConfig
from terminaltexteffects.engine.base_effect import BaseEffect, BaseEffectIterator
from terminaltexteffects.engine.space3d import Body, Space3D
from terminaltexteffects.utils import argutils
START_DISTANCE = 200
"""How far behind the canvas the sheet starts, in columns."""
SPIN_FRAMES = 240
"""Frames from the start until the sheet lands."""
SHADOW_COLOR = Color("#303030")
"""Color of the text when it faces away from the light."""
FINAL_GRADIENT = Gradient(Color("#8A008A"), Color("#00D1FF"), Color("#FFFFFF"), steps=12)
"""Colors of the text facing the light, top to bottom."""
HIDE_BACK = False
"""Whether to hide the text while its back faces the viewer, instead of showing it mirrored in shadow."""
def get_effect_resources() -> tuple[str, type[BaseEffect], type[BaseConfig]]:
"""Return the command name, effect class, and configuration class TTE registers."""
return "myspin", MySpin, MySpinConfig
@dataclass
class MySpinConfig(BaseConfig):
"""Configuration for the MySpin effect. It has no options yet."""
parser_spec = argutils.ParserSpec(
name="myspin",
help="The text tumbles in from the distance as a flat sheet, spins, and settles into place.",
description="myspin | The text tumbles in from the distance as a flat sheet, spins, and settles into place.",
epilog="Example: tte myspin",
)
class MySpinIterator(BaseEffectIterator[MySpinConfig]):
"""Produce the frames of the MySpin effect."""
def __init__(self, effect: MySpin) -> None:
"""Mount the text on a sheet far behind the canvas and queue its approach."""
super().__init__(effect)
self.final_colors: dict[EffectCharacter, ColorPair] = {}
self.space = Space3D(self.terminal, perspective=1, light="front")
self.build()
def build(self) -> None:
"""Shade and mount every visible character, move the sheet back, tip it, and queue the settle and approach."""
final_gradient_mapping = FINAL_GRADIENT.build_coordinate_color_mapping(
self.terminal.canvas.text_bottom,
self.terminal.canvas.text_top,
self.terminal.canvas.text_left,
self.terminal.canvas.text_right,
Gradient.Direction.VERTICAL,
)
characters = [character for character in self.terminal.get_characters() if character.input_symbol != " "]
for character in characters:
final_color = final_gradient_mapping[character.input_coord]
self.final_colors[character] = ColorPair(fg=final_color)
# The mount's light reading picks the frame: shadow when the text faces away, the final color facing
# the light.
scene = character.animation.new_scene(sync=Scene.SyncMetric.LIGHT)
scene.apply_gradient_to_symbols(
character.input_symbol, 1, fg_gradient=Gradient(SHADOW_COLOR, final_color, steps=10)
)
character.animation.activate_scene(scene)
self.terminal.set_character_visibility(character, is_visible=True)
self.active_characters.add(character)
self.sheet = self.space.body()
self.sheet.add_chars(characters, self.sheet.text_plane(characters), hide_when_facing_away=HIDE_BACK)
# The anchors are placed for the sheet's pose at rest, so move the sheet after mounting.
self.sheet.set_position(0, 0, -START_DISTANCE)
self.sheet.random_pose()
self.sheet.settle("y", turns=2, frames=SPIN_FRAMES, ease=easing.out_cubic)
self.sheet.move_to(0, 0, 0, frames=SPIN_FRAMES, ease=easing.out_cubic, together=True)
self.sheet.on_complete(self.finish)
def finish(self, sheet: Body) -> None:
"""Hand the characters back, on their input cells, and show them in their final colors."""
sheet.release_all()
for character, colors in self.final_colors.items():
character.animation.deactivate_scene()
character.animation.set_appearance(character.input_symbol, colors)
def __next__(self) -> str:
"""Move the sheet one frame, then the characters with it."""
if self.space.animating or self.active_characters:
self.space.step()
self.update()
return self.frame
raise StopIteration
class MySpin(BaseEffect[MySpinConfig]):
"""The text tumbles in from the distance as a flat sheet, spins, and settles into place."""
@property
def _config_cls(self) -> type[MySpinConfig]:
return MySpinConfig
@property
def _iterator_cls(self) -> type[MySpinIterator]:
return MySpinIterator
What changed
Two lines replace the spin call:
random_pose() turns the sheet to a random orientation right away, drawn from the space's random number generator.
settle spins about an axis while it unwinds every other part of the rotation, and lands exactly at rest. A plain
spin from a tilted pose would keep the tilt: it turns about the world's vertical axis, so the sheet would wobble
around it and finish tilted.
Run it
The starting pose is random, so each run tumbles in differently.
Next step
Step 6 turns the constants into options and handles colored input.
